凯斯零件查询(FLEX-AIR) - APPLICATOR (1995-1997) (2/95-2/97) (04-002) - BOOM GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
258 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN10465
|
[6] |
NIPPLE, LUBE,1/4"-28 st
|
BN
NIPPLE
|
| 2. |
BN65661
|
[1] |
PIN,31.75mm OD x 66.8mm L
|
BN
1.50 DIA x 2.88
|
| . . |
BN15256
|
[1] |
PIN,31.75mm OD x 63.5mm L
|
BN
1.25" Dia x 2.50" Superseded by part number: BN65661
|
| 3. |
BN15497
|
[16] |
CLAMP,76.2mm - 82.55mm
|
BN
3 1/4", SS, T-Bolt
|
| 4. |
BN68662
|
[2] |
BASE
|
BN
Boom Tip Cradle
|
| 5. |
BN19820
|
[4] |
SPACER,10.92mm ID x 22.1mm OD x 36.2mm L
|
BN
plastic .37 id x 1.42
|
| 6. |
BN23267A
|
[2] |
SLIDER
|
BN
Nylatron .5 x 2.0 x 7.0
|
| 7. |
BN24468
|
[4] |
SPRING
|
BN
tension 1.25" x 5.5"
|
| 8. |
BN24504
|
[4] |
LEVER
|
CUR
Takeup, Spring
|
| 9. |
BN35534
|
[1] |
BOOM
|
TYR
Inner RH
|
| . . |
BN35535
|
[1] |
BOOM
|
TYR
Inner LH
|
| 10. |
BN35536
|
[1] |
BOOM
|
BN
Mid RH
|
| . . |
BN35537
|
[1] |
BOOM
|
TYR
mid LH
|
| 11. |
BN35538
|
[1] |
BOOM
|
TYR
Breakaway RH
|
| . . |
BN35539
|
[1] |
BOOM
|
TYR
Breakaway LH
|
| 12. |
BN35558
|
[2] |
ARM
|
BN
control link
|
| 13. |
BN35561
|
[1] |
ARM
|
BN
Fold, Front, RH
|
| . . |
BN35562
|
[1] |
ARM
|
BN
Fold, Front, LH
|
| 14. |
BN35563
|
[1] |
ARM
|
BN
Fold, Rear, RH
|
| . . |
BN35564
|
[1] |
ARM
|
BN
Fold, Rear, LH
|
| 15. |
BN66864
|
[2] |
CYLINDER
|
BN
2.5 x 10, with Uniball
|
| 16. |
BN35703
|
[2] |
CYLINDER
|
BN
2.5" X 20"
|
| 17. |
BN69944
|
[2] |
PIN
|
BN
Breakaway
|
| 18. |
BN69947
|
[2] |
PIN
|
BN
Boom, Mid Section
|
| 19. |
BN35850
|
[2] |
BRACKET
|
BN
Spring, Breakaway
|
| 20. |
BN35851
|
[2] |
LATCH
|
BN
Breakaway
|
| 21. |
BN35853
|
[2] |
SUPPORT
|
BN
Latch, Breakaway
|
| 22. |
BN35892
|
[2] |
ARM
|
BN
Suspension
|
| 23. |
BN55198
|
[4] |
ROLL PIN
|
BN
3/8 X 2-1/2, SS Superseded by part number: 84204174
|
| 24. |
344018A1
|
[8] |
DEFLECTOR
|
TYR
RH
|
| . . |
BN65386
|
[8] |
DEFLECTOR
|
BN
LH Superseded by part number: 344015A1
|
| 25. |
BN68663
|
[2] |
SUPPORT
|
TYR
Boom Tip
|
| 26. |
BN65473
|
[2] |
SUPPORT
|
BN
Boom Tip
|
| 27. |
BN10057
|
[4] |
LUBE NIPPLE,1/4"-28 x 90
|
BN
|
| 28. |
BN68086
|
[16] |
CAP
|
BN
Round, Rubber, .25 ID
|
