凯斯零件查询(FLEX-AIR) - APPLICATOR (1995-1997) (2/95-2/97) (04-005) - BOOM GROUP, 2.5" TUBES, OUTER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
432 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN10465
|
[10] |
NIPPLE, LUBE,1/4"-28 st
|
BN
NIPPLE
|
| 2. |
BN50146
|
[4] |
WASHER,3/8", Stainless
|
BN
|
| 3. |
BN50179
|
[8] |
WASHER
|
BN
1.25 OD X ER, .25 ID X 1.00
|
| 4. |
BN50594
|
[2] |
BOLT,1/2"-13 x 1.75", Stainless
|
BN
|
| 5. |
BN50604
|
[4] |
COTTER PIN
|
BN
1/8 X 1&1/2 Superseded by part number: 80708
|
| 6. |
BN50759
|
[2] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 7. |
BN52335
|
[8] |
E-RING,1"
|
BN
E-Type, 1", SST
|
| 8. |
BN52336
|
[4] |
CLIP
|
BN
E-Type, 3/4", SST
|
| 9. |
BN55363
|
[6] |
LOCK NUT,1/2"-13, Nylon, Stainless
|
BN
|
| 10. |
BN55369
|
[2] |
BOLT,1/2"-13 x 3", Stainless
|
BN
|
| 11. |
BN55372
|
[2] |
BOLT,1/2"-13 x 3.25", Stainless
|
BN
|
| 12. |
BN55373
|
[2] |
BOLT,3/8"-16 X 3-1/2", Stainless Steel
|
BN
|
| 13. |
87271751
|
[8] |
CLAMP
|
BN
Hi-Torque
|
| 14. |
BN67861
|
[4] |
PIN,26.42mm OD x 50.8mm L
|
BN
Mid Boom Fold
|
| 15. |
BN68086
|
[8] |
CAP
|
BN
Round, Rubber, .25 ID X 1.00
|
| 16. |
BN68396
|
[4] |
DEFLECTOR
|
BN
Assembly, 2.5, RH Superseded by part number: BN325678
|
| 16. |
BN68397
|
[4] |
DEFLECTOR
|
BN
Assembly, 2.5, LH Superseded by part number: BN325678
|
| 17. |
BN69195
|
[1] |
BOOM
|
TYR
Mid, 2.50, RH
|
| 17. |
BN69196
|
[1] |
BOOM
|
TYR
Mid, 2.50, LH
|
| 18. |
BN69197
|
[1] |
BOOM
|
TYR
Outer, 2.50, RH
|
| 18. |
BN69198
|
[1] |
BOOM
|
TYR
Outer, 2.50, LH
|
| 19. |
BN69290
|
[2] |
LINK
|
BN
Breakaway
|
| 20. |
BN69294
|
[2] |
ROLLER
|
BN
Breakaway
|
| 21. |
BN69295
|
[2] |
SPACER
|
BN
Breakaway
|
| 22. |
BN69452
|
[28] |
SPRING
|
BN
Disc - 1.5 X .515 X .07
|
| 23. |
BN69456
|
[2] |
LINK
|
BN
Boom Fold, RH
|
| 24. |
BN69457
|
[2] |
LINK
|
BN
Boom Fold, LH
|
| 25. |
BN69466
|
[2] |
SPACER
|
BN
Boom Fold Links
|
| 26. |
BN69467
|
[2] |
STOP
|
BN
Breakaway
|
