凯斯零件查询(FLEX-AIR) - APPLICATOR (1995-1997) (2/95-2/97) (04-004) - BOOM GROUP, 2.5" TUBES, MID Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
645 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
342226A1
|
[4] |
DEFLECTOR
|
CUR
Assembly-Rear SS INS
|
| 2. |
BN35508
|
[1] |
Airway, RH, Mid
|
|
| 3. |
BN35509
|
[1] |
Airway, LH, Mid
|
|
| 4. |
BN35642
|
[2] |
SUPPORT
|
BN
Hinge, Mid
|
| 5. |
BN35718
|
[4] |
SUPPORT
|
BN
Rear Tubes
|
| 6. |
BN35882
|
[1] |
SUPPORT
|
BN
Hinge, Mid, RH
|
| 7. |
BN35883
|
[1] |
SUPPORT
|
BN
Hinge, Mid, LH
|
| 8. |
BN50138
|
[36] |
WASHER,1/4", SS
|
BN
|
| 9. |
BN50142
|
[16] |
WASHER,5/16", Stainless Steel
|
BN
|
| 10. |
BN50476
|
[16] |
BOLT,5/16"-18 x 0.75", Stainless
|
BN
|
| 11. |
BN50593
|
[4] |
BOLT,1/2"-13 x 1-1/2", Stainless Steel
|
BN
|
| 12. |
BN50595
|
[4] |
WASHER,1/2", Stainless
|
BN
|
| 13. |
BN55359
|
[36] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 14. |
BN55361
|
[16] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 15. |
BN55363
|
[4] |
LOCK NUT,1/2"-13, Nylon, Stainless
|
BN
|
| 16. |
BN65238
|
[1] |
SUPPORT
|
TYR
Cradle, Mid, LH
|
| 17. |
BN65239
|
[1] |
SUPPORT
|
TYR
Cradle, Mid, RH
|
| 18. |
BN65724
|
[1] |
HINGE
|
TYR
Boom, Mid, RH
|
| 19. |
BN65725
|
[1] |
HINGE
|
TYR
Boom, Mid, LH
|
| 20. |
87271751
|
[4] |
CLAMP
|
BN
Hi-Torque
|
| 21. |
BN67489
|
[4] |
CLAMP,63.5mm ID
|
BN
Pneumatic, 2.50
|
| 22. |
BN68086
|
[4] |
CAP
|
BN
Round, Rubber, .25 ID X 1.00
|
| 23. |
BN68398
|
[1] |
TUBE
|
BN
Support, Mid, RH
|
| 24. |
BN68399
|
[1] |
TUBE
|
BN
Support, Mid, LH
|
| 25. |
BN69283
|
[2] |
TUBE
|
BN
2.5 OD X 16 GA X 150.00
|
| 26. |
BN69284
|
[2] |
TUBE
|
BN
2.5 OD X 16 GA X 100.00
|
| 27. |
BN69292
|
[2] |
TUBE
|
BN
2.50, 45 X 37.75
|
| 28. |
BN300326
|
[1] |
VENTURI
|
BN
Assembly, 2.5, RH
|
| 29. |
BN300327
|
[1] |
VENTURI
|
TYR
Assembly, 2.5, LH
|
| 30. |
BN69298
|
[2] |
TUBE
|
TYR
2.50, 45 X 17.75
|
| 31. |
87266747
|
[16] |
U-BOLT
|
CUR
1/4"-20 x 2.5 ID x 3"
|
| 32. |
BN21276
|
[2] |
CLAMP
|
BN
2 1/2" Muffler
|
| 33. |
BN8171009
|
[1] |
Frame Extension 18"
|
|
