神钢零件查询(MD320BLC) - EXCAVATOR BTW YC0301 - YC0747 (1/80-12/06) (01-003) - MOTOR ASSY, SWING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
547 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J10325F2 | [1] | MOTOR ASSY, SWING | MOTOR ASSY, SWING |
| 1. | 2401N461 | [1] | SHAFT, PINION | SHAFT, PINION |
| 3. | ZD11G13000 | [1] | O-RING,129.40mm ID x 135.60mm OD x 3.10mm | KOB |
| 6. | ZS23C12045 | [12] | SCREW,Hex Socket Head, M12 x 45mm | KOBM12x1.75x45mm Superseded by part number: ZS28C12045 |
| 7. | 2425Z522 | [1] | BEARING | BEARING |
| 8. | 2414J1134 | [1] | HOUSING | KOB |
| 9. | 2418T17014 | [1] | SPACER | KOB |
| 10. | 25Z494D16 | [1] | BEARING | KOB |
| 11. | ZR16X12000 | [1] | SNAP RING | KOBRetaining -- ID 113 x OD 120 x Th 4.0mm |
| 12. | 2418T17015 | [1] | SPACER | KOB |
| 13. | 2413J366 | [1] | SPIDER | KOB |
| 14. | 2401P672 | [1] | SUN GEAR | KOB |
| 15. | 2401N460 | [1] | GEAR | KOB |
| 16. | 2413N434F1 | [1] | SPIDER | KOB |
| 17. | 2420T6607 | [12] | SCREW | KOB |
| 19. | 2401P671 | [1] | SUN GEAR | KOB |
| 20. | ZS23C08018 | [8] | BOLT,Hex Socket Head, M8 x 18mm | KOBM08x1.25x18mm |
| 21. | 2418T13572 | [4] | LOCKING PLATE | KOB |
| 22. | 2410P782 | [4] | SHAFT | KOB |
| 23. | 2418T17017 | [8] | THRUST WASHER | KOB |
| 24. | 2401P674 | [4] | PINION | KOB |
| 25. | 2418T17018 | [8] | WASHER | KOB |
| 26. | 2401P673 | [4] | PINION | KOB |
| 27. | ZR16X06000 | [4] | RING | KOB |
| 28. | 2418T17425D3 | [1] | PIPE | PIPE |
| 29. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 30. | ZR16X04500 | [1] | RING | KOBRetaining -- ID 45 x OD 58 x Th 1.8mm |
| 31. | ZS83C20020 | [2] | SCREW | KOBSet -- M20x2.50x20mm |
| 32. | 2441U760F1 | [1] | HYDRAULIC MOTOR | KOB Superseded by part number: 2441U760F2 |
| 32-1. | 2436U1241F2 | [1] | CONTROL VALVE | KOB |
| 32-2. | 2441U784F1 | [1] | MOTOR | KOB Superseded by part number: 2441U784F2 |
| 32-3. | 2436U1283F1 | [1] | VALVE PRESSURE RELIE | KOB |
| 32-4. | ZS23C12110 | [8] | SCREW,Hex Socket Head, M12 x 110mm | KOBM12x1.75x110mm Superseded by part number: ZS28C12110 |
| 32-5. | ZD12G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 33. | 2418T19863 | [1] | HOSE | KOB |
| 34. | 2418R2D70 | [1] | SNAP RING | KOB |
| 35. | 2418T19864 | [1] | PLATE | KOB |
| 36. | 2418T19865 | [1] | PLATE | KOB |
| 37. | 2418R248 | [1] | OIL SEAL | KOB |
| 38. | 2418P21404 | [1] | RETAINER | KOB |
| 39. | 2418T19862 | [1] | SPACER | KOB |
