神钢零件查询(MD320BLC) - EXCAVATOR BTW YC0301 - YC0747 (1/80-12/06) (11-029) - MOTOR ASSY, (SWING) 2441U784 F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
523 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U784F1 | [1] | MOTOR | KOBASSY, SWING, CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2441U784F2 |
| 11. | 2441U784S11 | [9] | PISTON | KOBPISTON ASSY, CONSISTS OF REF 121, 122 |
| 20. | 2441U784S20 | [1] | REPAIR KIT | KOBCOVER ASSY. VALVE, CONSISTS OF REF 303, 451 |
| (031). | 2436U1283F1 | [1] | VALVE PRESSURE RELIE | KOBREDUCTION, SEE FIG 11-014 |
| 101. | 2441U784S101 | [1] | SHAFT | KOB |
| 106. | 2441U784S106 | [3] | SPACER | KOB |
| 111. | 2441U784S111 | [1] | CYLINDER | KOB Superseded by part number: LC15V00003S111 |
| 113. | 2441U784S113 | [1] | BUSHING | KOB |
| 114. | 2441U784S114 | [1] | SPRING | KOB Superseded by part number: 2441U785S114 |
| 116. | 2441U784S116 | [12] | PUSH ROD | KOB |
| 117. | 2441U784S117 | [1] | SPACER | KOB |
| 118. | 2441U784S118 | [1] | SPACER | KOB |
| 121. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON |
| 122. | NSS | [9] | NOT SOLD SEPARAT | CONSHOE |
| 123. | 2441U784S123 | [1] | PLATE | KOB |
| 124. | 2441U784S124 | [1] | PLATE | KOB |
| 131. | 2441U784S131 | [1] | PILOT VALVE | KOB |
| 301. | 2441U784S301 | [1] | HOUSING | KOBCASING |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER, VALVE |
| 304. | 2441U784S304 | [1] | BODY | KOB |
| 401. | ZS23C22045 | [4] | SCREW | KOB |
| 432. | ZR16X05000 | [2] | RING | KOBRetaining -- ID 50 x OD 64 x Th 2.0mm |
| 433. | ZR16X02500 | [1] | RING | KOBRetaining -- ID 23.2 x OD 25 x Th 1.2mm |
| 437. | ZR26X11000 | [1] | LOCKING RING | KOB |
| 438. | ZR26X06200 | [1] | SNAP RING | KOB |
| 443. | 2441U549S443 | [1] | ROLLER BEARING | KOB |
| 444. | 2441U784S444 | [1] | ROLLER BEARING | KOB |
| 451. | ZP26D08016 | [2] | ROLL PIN | KOB |
| 464. | 2441U667S466 | [1] | PLUG | KOB1/4" PF |
| 471. | ZD12G11000 | [1] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOBID 109.4 ± 0.91 x OD 115mm |
| 472. | 2441U784S472 | [1] | O-RING | KOB |
| 485. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 491. | 2441U549S491 | [1] | OIL SEAL | KOB Superseded by part number: 24100U84S25 |
| 702. | 2441U784S702 | [1] | PISTON | KOB |
| 706. | 2415U188S725 | [1] | O-RING | KOB |
| 707. | 2441U784S707 | [1] | O-RING | KOB |
| 712. | 2441U784S712 | [22] | SPRING | KOB |
| 742. | 2441U784S742 | [2] | CLUTCH PLATE | KOB |
| 743. | 2441U784S743 | [3] | PLATE | KOB |
| 992. | ZE82T08000 | [1] | PLUG | KOB1/2" PT |
| 994. | ZE82T12000 | [1] | PLUG | KOB3/4" PT |
