凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (01-014) - BELT CARTRIDGE GROUP, FLEX, 60’ & 70’ Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
164 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN311142
|
[2] |
ELBOW
|
BN
Fitting, Body-90 Degree
|
| 2. |
BN10500
|
[4] |
FLANGED BEARING,25.4mm ID
|
BN
Flange 1"
|
| 3. |
343498A1
|
[1] |
PULLEY
|
BN
conv-tapered (Vulcan)
|
| 4. |
BN35404
|
[2] |
ADJUSTER
|
BN
Takeup-Weldment
|
| 5. |
343499A1
|
[1] |
PULLEY
|
BN
Conveyor, Volcanized
|
| 6. |
BN35805
|
[4] |
ADAPTER
|
BN
str 1/8 npsm-nptf
|
| 7. |
BN50062
|
[6] |
LOCK NUT,3/8"-16, Stainless Steel
|
BN
|
| 8. |
BN50138
|
[12] |
WASHER,1/4", SS
|
BN
|
| 9. |
BN50146
|
[6] |
WASHER,3/8", Stainless
|
BN
|
| 10. |
BN50237
|
[8] |
BOLT,5/16"-18 X 1-1/2", Stainless Steel
|
BN
|
| 11. |
BN50254
|
[6] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 12. |
BN50529
|
[4] |
NUT
|
BN
5/8-11, HH, SS
|
| 13. |
BN50671
|
[6] |
BOLT,1/4"-20 x 1.00", Stainless Steel
|
BN
|
| 14. |
BN53567
|
[2] |
ADAPTER
|
BN
1/4"-28 x 1/8" nptf Superseded by part number: 86580291
|
| 15. |
BN53570
|
[4] |
BHD LOCK NUT
|
BN
|
| 16. |
BN55359
|
[6] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 17. |
BN55361
|
[8] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 18. |
BN63524
|
[1] |
FRAME
|
BN
Floor & Roller
|
| 19. |
BN63531
|
[1] |
MOUNTING PLATE
|
BN
W/M-Roller, LH
|
| 20. |
BN63532
|
[1] |
MOUNTING PLATE
|
BN
W/M-Roller, RH
|
| 21. |
BN67993
|
[2] |
BRACKET
|
BN
Grease Line, Conv.
|
| 22. |
BN67999
|
[2] |
HOSE
|
BN
Grease, 9"
|
| 23. |
BN68186
|
[2] |
HOSE
|
BN
Grease, 32.00
|
| 24. |
BN69951
|
[4] |
CAP
|
BN
Grease
|
| 25. |
BN15031
|
[1] |
CONVEYOR BELT,26.50" W x 53.25" L
|
BN
|
