凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (01-013) - PARTS GROUP, BELT CARTRIDGE, 60’ & 70’ Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
670 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN21398A
|
[4] |
COUPLING
|
BN
Machined
|
| 2. |
BN22884
|
[2] |
KIT
|
BN
Adaptor
|
| 3. |
126-124
|
[4] |
WOODRUFF KEY,#15, 1/4" x 1", HT
|
CAS
Superseded by part number: 47471
|
| 4. |
BN307005
|
[2] |
SPACER
|
BN
Cartridge Mount
|
| 5. |
BN307006
|
[2] |
SECURING STRAP
|
BN
Cartridge Mount
|
| 6. |
NS
|
[2] |
NOT SERVICED
|
BAS
Belt-T Pulley
|
| 7. |
BN35888
|
[2] |
ARM
|
TYR
Torque Arm-Conveyor
|
| 8. |
BN50146
|
[4] |
WASHER,3/8", Stainless
|
BN
|
| 9. |
BN50212
|
[8] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 10. |
BN50250
|
[8] |
BOLT,3/8"-16 x 3/4", Stainless Steel
|
BN
Superseded by part number: 113-2299
|
| 11. |
BN50254
|
[8] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 12. |
BN50258
|
[12] |
BOLT,3/8"-16 X 1.25", Stainless
|
BN
|
| 13. |
BN50421
|
[4] |
SET SCREW
|
BN
5/16"-18 X 1/2"
|
| 14. |
BN50473
|
[4] |
SET SCREW
|
BN
5/16"-18 X 3/4"
|
| 15. |
BN50759
|
[20] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 16. |
BN55359
|
[8] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 17. |
BN65718
|
[2] |
HYDRAULIC MOTOR
|
BN
Conveyor Belt
|
| 18. |
BN314948
|
[2] |
SENSOR
|
BN
APPLIC. Rate
|
