凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (01-016) - METER SYSTEM PARTS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
799 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87265982
|
[32] |
SPACER
|
BN
Divider, Flex-Air
|
| 4. |
BN300592
|
[4] |
SEAL
|
BN
Seal, Door, Side
|
| 5. |
BN307040
|
[14] |
DIVIDER
|
BN
|
| 6. |
BN307041
|
[4] |
DIVIDER
|
BN
W/Tab
|
| 7. |
BN307226
|
[2] |
SUPPORT
|
BN
Air Manifold
|
| 8. |
BN307595
|
[2] |
DOOR SEAL
|
BN
Seal, Door, Bottom
|
| 9. |
BN307596
|
[2] |
DOOR
|
TYR
Divider
|
| 10. |
BN35414
|
[4] |
ROD
|
BN
THD, 3/8-16 UNC X 24.75
|
| 11. |
BN50062
|
[8] |
LOCK NUT,3/8"-16, Stainless Steel
|
BN
|
| 13. |
BN50146
|
[20] |
WASHER,3/8", Stainless
|
BN
|
| 15. |
BN50254
|
[10] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 17. |
BN50759
|
[30] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 20. |
87267275
|
[1] |
LADDER
|
BN
Lower
|
| 21. |
87267279
|
[1] |
MOUNTING PLATE
|
BN
Ladder
|
| 24. |
BN68581
|
[2] |
GASKET
|
BN
Venturi To Divider
|
| 25. |
BN71007
|
[4] |
CLIP,3/16" Hairpin
|
BN
Hairpin, 3/16" #8
|
| 26. |
343299A1
|
[4] |
SET SCREW,3/8"-16 X 1.00", Stainless Steel
|
BN
|
| 27. |
BN9990114
|
[19] |
STRAP
|
BN
Ty Rap, "Eye Ty" 06205 3M
|
| 28. |
BN310266
|
[19] |
BHD LOCK NUT,#10-24, Nylon, Stainless Steel
|
BN
|
| 30. |
86986185
|
[2] |
STOP DEVICE
|
BN
Divider
|
| 31. |
87267748
|
[12] |
PLUG
|
BN
Foam
|
