凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (01-018) - FAN GROUP, 6” CCW Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
387 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN15736
|
[1] |
PLATE
|
BN
Sensor, 2 Lobe
|
| 2. |
87267658
|
[1] |
SENSOR
|
BN
Fan Sensor, With Mounting
|
| 3. |
BN23453
|
[1] |
MOUNTING PLATE
|
BN
RPM Sensor
|
| 4. |
BN23813
|
[1] |
GASKET
|
BN
.060" Polypropylene
|
| 5. |
BN35697
|
[1] |
HYDRAULIC MOTOR
|
BN
MTR, .73 Rex
|
| . . |
BN35697R
|
[1] |
REMAN-HYD MOTOR
|
BN
FLX810 (10/03-8/09)
|
| . . |
BN35697C
|
[1] |
CORE-MOTOR HYDRAULIC
|
BN
Return Number
|
| 6. |
BN35698
|
[1] |
BUSHING
|
BN
Taper 20MM
|
| . . |
14723410
|
[1] |
KEY
|
COE
Not Shown, Used Between Ref 5 and Ref 6
|
| 7. |
BN35702
|
[1] |
FAN
|
BN
HP, 6 Inch, CCW Superseded by part number: 87265705
|
| 8. |
BN50142
|
[2] |
WASHER,5/16", Stainless Steel
|
BN
|
| 9. |
BN50212
|
[2] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 10. |
BN50232
|
[1] |
BOLT,5/16"-18 x 1.00", Stainless Steel
|
BN
|
| 11. |
BN50594
|
[2] |
BOLT,1/2"-13 x 1.75", Stainless
|
BN
|
| 12. |
BN50595
|
[2] |
WASHER,1/2", Stainless
|
BN
|
| 13. |
BN50697
|
[6] |
BOLT,Hex, 1/4" - 20 x 1/2", SST
|
BN
|
| 14. |
BN55359
|
[2] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 15. |
BN55361
|
[1] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 16. |
BN55363
|
[2] |
LOCK NUT,1/2"-13, Nylon, Stainless
|
BN
|
| 18. |
86986864
|
[1] |
MOUNTING PLATE
|
BN
Sensor
|
| 19. |
86986599
|
[1] |
SCREEN
|
BN
Blower Superseded by part number: 1020543, 1020540
|
