凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (01-025) - BOOMS HYDRAULIC TUBES GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
826 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN29779
|
[3] |
CLAMP
|
BN
Dual, 1/2" Tube
|
| 2. |
BN306967
|
[1] |
TUBE
|
BN
Boom Level, LH, Rod
|
| 3. |
BN306968
|
[1] |
TUBE
|
BN
Boom Tip, LH, Rod
|
| 4. |
BN306969
|
[1] |
TUBE
|
BN
Boom Tip, LH
|
| 5. |
BN306970
|
[1] |
TUBE
|
BN
Boom Level, LH
|
| 6. |
BN306971
|
[1] |
TUBE
|
BN
Boom Level, RH
|
| 7. |
BN306972
|
[1] |
TUBE
|
BN
Boom Tip, RH
|
| 8. |
BN306973
|
[1] |
TUBE
|
BN
Boom Tip, RH
|
| 9. |
BN306974
|
[1] |
TUBE
|
BN
Boom Level, RH, Rod
|
| 10. |
BN307911
|
[19] |
CLAMP
|
BN
Dual, 3/8 Tube
|
| 11. |
BN309486
|
[12] |
PLATE
|
BN
Top Plate, Dual, Size 1
|
| 12. |
BN50138
|
[8] |
WASHER,1/4", SS
|
BN
|
| 13. |
BN55359
|
[12] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 14. |
BN55366
|
[2] |
BOLT,1/4"-20 x 2.00", Stainless Steel
|
BN
|
| 15. |
BN67050
|
[10] |
BOLT,1/4"-20 X 3.00", Stainless Steel
|
BN
|
| 16. |
BN305412
|
[16] |
O-RING
|
BN
FOR -6 FOR Superseded by part number: 9993141
|
