凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (01-026) - CONVEYOR AND AUGER HYDRAULIC TUBES GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
324 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN29783
|
[3] |
CLAMP
|
BN
Single, 1/2" Tube
|
| 2. |
BN306975
|
[1] |
TUBE
|
BN
8 Gate
|
| 3. |
BN306976
|
[1] |
TUBE
|
BN
8 Gate, Rod
|
| 4. |
BN306981
|
[1] |
TUBE
|
TYR
Conveyor, RH
|
| 5. |
BN307082
|
[1] |
CLAMP
|
BN
Pair 1.25" Tube
|
| 6. |
BN307911
|
[6] |
CLAMP
|
BN
Dual, 3/8 Tube
|
| 7. |
BN307913
|
[1] |
CLAMP
|
BN
Dual, 1/2 Pipe
|
| 8. |
BN309483
|
[1] |
PLATE
|
BN
Single, Size 5
|
| 9. |
BN309484
|
[1] |
PLATE
|
BN
Dual, Size 3
|
| 10. |
BN309485
|
[3] |
PLATE
|
BN
Single, Size 2
|
| 11. |
BN309486
|
[3] |
PLATE
|
BN
Dual, Size 1
|
| 12. |
BN309848
|
[1] |
SCREW,Hex, 5/16" - 18 x 3", SST
|
BN
|
| 13. |
BN309849
|
[1] |
CLAMP
|
BN
Dual, 1.25 Tube
|
| 14. |
BN309850
|
[2] |
PLATE
|
BN
Dual, Size 5
|
| 15. |
BN50241
|
[1] |
BOLT,5/16"-18 X 2-1/4", Stainless Steel
|
BN
|
| 16. |
BN55359
|
[11] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 17. |
BN55361
|
[3] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 18. |
BN55366
|
[6] |
BOLT,1/4"-20 x 2.00", Stainless Steel
|
BN
|
| 19. |
BN67050
|
[5] |
BOLT,1/4"-20 X 3.00", Stainless Steel
|
BN
|
| 20. |
BN311570
|
[2] |
CLAMP
|
BN
Dual, 1.50 Tube
|
| 21. |
BN309845
|
[1] |
SCREW,Hex, 5/16" - 18 x 5", SST
|
BN
|
| 22. |
BN305412
|
[4] |
O-RING
|
BN
For -6 FFOR Superseded by part number: 9993141
|
| 23. |
BN305413
|
[2] |
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
|
BN
For -8 FFOR Superseded by part number: 9992298
|
