| . . | 24100J11063F1 | [1] | WIRE HARNESS | KOB |
| 1. | 24101J145 | [1] | DIAGRAM WIRING | |
| 2. | 2479R1368 | [1] | RELAY | KOB |
| 3. | NSS | [3] | NOT SOLD SEPARAT | CONLIGHT ASSY |
| 4. | 2479U1009F1 | [1] | HORN,24V, 390HZ | KOBHigh (415Hz) Superseded by part number: CM53S00002F1 |
| 5. | 2479U1009F2 | [1] | HORN,24V, 350HZ | KOBLow (390Hz) Superseded by part number: CM53S00002F2 |
| G. | 2486R73D1 | [1] | NEG BATTERY CABLE | KOB |
| 7. | 2486R74D1 | [1] | NEG BATTERY CABLE | KOB |
| 8. | 2486R75D2 | [1] | NEG BATTERY CABLE | KOB |
| 9. | 2486R76D5 | [1] | ELECTRIC CABLE | KOB |
| 10. | 2479U1114 | [1] | HARNESS | KOB, Serial Range: YC0301-YC0304 |
| . . | 2479U1180 | [1] | WIRE HARNESS | KOB, Start Serial: YC0305 |
| 11. | 2479U1142 | [1] | HARNESS, WIRING | HARNESS, WIRING |
| 12. | 2479Z1005D3 | [1] | WIRE HARNESS | KOB |
| 13. | 2432Z270 | [7] | CLAMP | KOB |
| 14. | 2420Z699 | [1] | GROMMET | KOB |
| 15. | 2420R372D124 | [2] | GROMMET | KOB |
| 20. | 2432R225D11 | [1] | CLIP | KOBClamp, Single -- ID 29 x 62.5mm Long, Start Serial: YC0432 Superseded by part number: ZC46X29011 |
| 21. | 2416T22160 | [1] | BRACKET | KOB |
| 22. | 2432R225D5 | [4] | CLIP | KOB Superseded by part number: ZC46X12011 |
| 23. | 2432R225D6 | [13] | CLIP | KOB |
| 24. | 2432R225D10 | [5] | CLIP | KOBClamp, Single -- ID 25.5 x 58.75mm Long Superseded by part number: ZC46X25011 |
| 25. | 2432R225D8 | [1] | CLIP | KOBClamp, Single -- ID 19.1 x 51.55mm Long Superseded by part number: ZC46X19011 |
| 26. | 2432R225D9 | [2] | CLIP | KOBClamp, Single -- ID 22 x 54mm Long, Serial Range: YC0301-YC0431 Superseded by part number: ZC46X22011 |
| . . | 2432R225D9 | [1] | CLIP | KOBClamp, Single -- ID 22 x 54mm Long, Start Serial: YC0432 Superseded by part number: ZC46X22011 |
| 27. | ZS31C05010 | [1] | BOLT,Phillips Drive, Pan HD, M5 x 10mm | KOBM05x0.8x10mm |
| 28. | ZW26X05000 | [1] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 29. | ZW16K05000 | [1] | WASHER | KOBID 05 x OD 10 x Th 1.0mm |
| 31. | ZN18C06005 | [9] | NUT | KOBM06x1.0mm |
| 32. | ZW26X06000 | [9] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 33. | ZW16K06000 | [2] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 35. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 36. | ZS18C08030 | [2] | SCREW,Hex, M8 x 30mm | KOBM08x1.25x30mm |
| 37. | ZN18C08007 | [2] | NUT | KOBM08x1.25mm |
| 38. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 39. | ZW16K08000 | [2] | WASHER,8mm ID x 15.5mm OD x 1.6mm Thk | KOBID 08 x OD 15.5 x Th 1.6mm |
| 40. | ZS18C10014 | [9] | SCREW,Hex, M10 x 14mm | KOBM10x1.50x14mm, See Figure 05-013 |
| 41. | ZS18C10030 | [1] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 42. | ZN18C10008 | [18] | NUT | KOBM10x1.50mm |
| 43. | ZW26X10000 | [28] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 44. | ZW16K10000 | [5] | WASHER | KOBID 10.5 x OD 18 x Th 2.0mm |
| 45. | 2432Z468 | [23] | CLIP | KOB |
| 46. | 2432Z290 | [4] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 47. | 2432Z290D3 | [4] | CLIP | KOBWire Ties -- 154mm Long Superseded by part number: PY01P01043D3 |
| 48. | 2479Z1777 | [1] | HARNESS | KOB |
| 52. | 2479Z1798 | [1] | WIRE HARNESS | KOB |
| 53. | 2479Z1799D2 | [1] | WIRE HARNESS | KOB |
