神钢零件查询(MD320BLC) - EXCAVATOR BTW YC0301 - YC0747 (1/80-12/06) (06-006) - RING, SLEWING 24100N3854F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
381 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N3854F2 | [1] | RING, SLEWING | RING, SLEWING |
| 2. | 2418P15662 | [2] | RIGID TUBE | KOB |
| 3. | 2410T306 | [2] | KNUCKLE JOINT | KOB |
| 4. | ZF33E08004 | [2] | ELBOW | KOB |
| 5. | ZF23E08004 | [2] | HYD CONNECTOR | KOB |
| 6. | ZG91S02000 | [3] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 7. | ZC45X08007 | [2] | CLAMP | KOB Superseded by part number: ZC46X08007 |
| 8. | ZS13C06010 | [2] | SCREW | KOBM06x1.0x10mm Superseded by part number: ZS18C06010 |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONRING, SLEWING, SEE FIG 06-007 |
