神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (01-004) - COUNTER-SECTION, ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
366 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2422N903F2 | [1] | CENTER-SECTION ASSY | |
| 1. | 24100N4073F1 | [1] | SHEAVE ASSY | |
| 1-1. | 2406N801D1F1 | [1] | LINK ASSY | |
| 1-1H. | 2405T1282D1 | [2] | BUSHING | |
| 1-3. | 2407T209F1 | [1] | SHEAVE ASSY | |
| 1-4. | 2407T148F1 | [1] | SHEAVE ASSY | |
| 1-5. | 2419T4752D2 | [1] | SHAFT | KOB |
| 1-6. | 2419T4433D4 | [1] | SHAFT | SHAFT |
| 1-7. | ZW16X42000 | [4] | WASHER ID 42 x OD 78 x Th 7.0mm | WASHER ID 42 x OD 78 x Th 7.0mm |
| 1-8. | ZP15008063 | [4] | PIN, SPLIT | |
| 1-9. | 2419T4432 | [1] | PIN | KOB |
| 1-10. | 2419R906 | [1] | PIN, SNAP | |
| 1-11. | 2420T5426 | [1] | BOLT | |
| 1-12. | ZN18C30024 | [1] | NUT | KOBM30x2.0mm |
| 2. | 24100N40752 | [1] | SHEAVE ASSY | |
| 2-1. | 2406N801D2FI | [1] | LINK ASSY | |
| 2-1H. | 2405TI282D1 | [2] | BUSHING | |
| 2-3. | 2407T209F1 | [1] | SHEAVE ASSY | |
| 2-4. | 2407T148F1 | [1] | SHEAVE ASSY | |
| 2-5. | 2419T4752D2 | [1] | SHAFT | KOB |
| 2-6. | 2419T4433D4 | [1] | SHAFT | SHAFT |
| 2-7. | ZW16X42000 | [4] | WASHER ID 42 x OD 78 x Th 7.0mm | WASHER ID 42 x OD 78 x Th 7.0mm |
| 2-8. | ZP15D08063 | [4] | BASE PLATE Pin, Cotter | BASE PLATE Pin, Cotter |
| 2-9. | 2419T4432 | [1] | PIN | KOB |
| 2-10. | 2419R9D6 | [1] | PIN | KOBSnap -- OD 16mm x 43.8mm Long |
| 2-11. | 2420T5426 | [1] | BOLT | |
| 2-12. | ZN18C30024 | [1] | NUT | KOBM30x2.0mm |
| 4. | 2422N904D2 | [1] | REWORK, CENTER-SECTION | |
