神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (01-003) - COUNTER-WEIGHT, REMOVE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
949 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6497F2 | [1] | COUNTER-WEIGHT REMOVE | |
| 2. | 2411N1459F1 | [1] | REWORK, BOOM | |
| 2-1. | 24100N4076F1 | [2] | SHEAVE ASSY | |
| 2-1A. | 2416N3338 | [1] | BRACKET | |
| 2-1B. | 2407T209F1 | [1] | SHEAVE ASSY | |
| 2-1C. | 2419T4752D1 | [1] | SHAFT | KOB |
| 2-10. | ZP15D08063 | [2] | BASE PLATE Pin, Cotter | BASE PLATE Pin, Cotter |
| 2-1E. | ZW16X42000 | [2] | WASHER ID 42 x OD 78 x Th 7.0mm | WASHER ID 42 x OD 78 x Th 7.0mm |
| 2-2. | ZS18C16035 | [16] | SCREW,Hex, M16 x 35mm | KOBM16x2.0x35mm |
| 2-3. | ZW16H16000 | [16] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 2-4. | 2411P1525 | [1] | REWORK, BOOM | |
| 3. | 2411N1460F1 | [1] | REWORK, ARM | |
| 3-1. | 2416N3339 | [1] | BRACKET | BRACKET |
| 3-2. | ZS18C16035 | [7] | SCREW,Hex, M16 x 35mm | KOBM16x2.0x35mm |
| 3-3. | ZW16H16000 | [7] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 4. | 2430R300D3 | [4] | ROPE ASSY, WIRE | |
| 5. | 2420Z604D4 | [4] | SHACKLE | SHACKLE |
| 6. | ZT13A65000 | [1] | SPANNER NOT SHOWN | SPANNER NOT SHOWN |
| 7. | 2422N903F2 | [1] | REWORK, CENTER-SECTION,SEE FIGURE 01-004 | |
| 8. | 2422P1190 | [1] | REWORK, CENTER-WEIGH | |
