凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (02-051) - LADDER GROUP, DOUBLE & TRIPLE BIN Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
759 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN05412
|
[1] |
PIN
|
BN
Locking, MW
|
| 2. |
BN308099
|
[1] |
HANDRAIL
|
TYR
Co-Ap Bin
|
| 3. |
BN308100
|
[1] |
SUPPORT
|
BN
Co-Ap Handrail
|
| 4. |
BN308104
|
[1] |
PIN
|
BN
Handrail Pivot
|
| 5. |
BN308105
|
[2] |
BUSHING
|
BN
Co-Ap Handrail
|
| 6. |
87267261
|
[1] |
LADDER
|
TYR
Co-Ap Bin-LH
|
| 7. |
BN310002
|
[2] |
BUMPER
|
BN
1.00 OD x 1.0H
|
| 8. |
BN31444
|
[1] |
PIN, ROLL
|
BN
1/4 X 1 1/2
|
| 9. |
BN31937
|
[1] |
SPRING
|
BN
Compressor, .905 X .765 2
|
| 10. |
BN50146
|
[22] |
WASHER,3/8", Stainless
|
BN
|
| 11. |
BN50178
|
[1] |
WASHER
|
BN
1.25 OD X .75 ID X 10 GA
|
| 12. |
BN50254
|
[14] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 13. |
BN50595
|
[2] |
WASHER,1/2", Stainless
|
BN
|
| 14. |
BN50602
|
[2] |
COTTER PIN
|
BN
1/8" X 1.25
|
| 15. |
BN50759
|
[14] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 16. |
BN55361
|
[2] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
