神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (02-007) - GUARD ASSY/ P.N. 24100X2116F7 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
954 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X2116F7 | [1] | GUARD ASSY | |
| 4. | 2414P4732 | [1] | COVER | COVER |
| 6. | 2414N2106 | [1] | COVER COVER | COVER COVER |
| 9. | 2414N2975 | [1] | COVER | |
| 10. | 2414P4733 | [1] | COVER | |
| 12. | 2414T2252 | [1] | COVER | |
| 14. | 2414N2861 | [1] | COVER | |
| 15. | 2414P3247 | [1] | COVER | |
| 16. | 2414P3248 | [1] | COVER | |
| 19. | 2416N3925 | [1] | BRACKET | BRACKET |
| 20. | 2416N3924 | [1] | BRACKET | BRACKET |
| 21. | 2416T8231 | [6] | BRACKET | KOB |
| 23. | 2416T6289D2 | [3] | STAY | KOB |
| 28. | ZN18C10008 | [13] | NUT | KOBM10x1.50mm |
| 29. | ZN18C05004 | [4] | NUT | KOBM05x0.8mm |
| 32. | 2418T5373C2 | [11] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 33. | ZW16H12000 | [10] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 36. | 2416T6915 | [2] | RUBBER | |
| 37. | 2418T6682 | [2] | SPACER | |
| 38. | 2419R9D3 | [3] | PIN | KOBHair -- OD 10mm x 32.6mm Long |
| 39. | 2416T6682 | [2] | RUBBER BAND | KOBCUSHION |
| 44. | 2420Z750 | [1] | GROMMET | GROMMET |
| 45. | ZW26X10000 | [49] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 46. | ZW16X10000 | [15] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 50. | 2479T425 | [1] | INSULATOR, SOUND | |
| 53. | 2418T13834D1 | [3] | SHIM | |
| 54. | 2418T13834D2 | [1] | SHIM | |
| 55. | 2418T13834D3 | [1] | SHIM | |
| 56. | 2418T13834D4 | [1] | SHIM | |
| 57. | 2416Z271D2 | [1] | INSULATOR | |
| 58. | 2416Z27001 | [1] | INSULATOR | |
| 75. | 2416T8567 | [4] | SHIM | |
| 77. | 2414P5195 | [1] | COVER | COVER |
| 82. | 24100J7727F2 | [1] | CAM SEE FIGURE 02-009 YS., Serial Range: 0101-YS.0012 | CAM SEE FIGURE 02-009 YS., Serial Range: 0101-YS.0012 |
| . . | 24100J7727F3 | [1] | CAM SEE FIGURE 02-009 YS., Start Serial: 0101 | CAM SEE FIGURE 02-009 YS., Start Serial: 0101 |
| 83. | 2414N3151 | [1] | COVER | COVER |
| 85. | ZS18C10025 | [52] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 86. | ZS18C10045 | [1] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 88. | ZS18C12030 | [10] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 90. | ZW26X12000 | [10] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 92. | 2414N3152 | [1] | COVER | COVER |
| 94. | 2414P5367 | [1] | COVER | |
| 95. | 24100J6510F1 | [1] | GUARD ASSY, SEE FIGURE 02-008 | |
