神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (02-008) - GUARD ASSY/ P.N. 24100J6510F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
384 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6510F1 | [1] | GUARD ASSY | |
| 1. | 2414J1070 | [1] | COVER | COVER |
| 2. | 2414J1069 | [1] | COVER | COVER |
| 2-5. | ZW11X12000 | [5] | WASHER | KOBID 12 x OD 24 x Th 2.3mm Superseded by part number: ZW16X12000 |
| 2-7. | 2416T6442D3 | [1] | STAY | |
| 2-8. | 2427T439 | [2] | HINGE | KOB Superseded by part number: 2420T4497 |
| 2-10. | B16T0530 | [1] | CLIP | CLIP |
| 2-11. | ZS16C06008 | [2] | CAPSCREW M06x1.0x08mm | CAPSCREW M06x1.0x08mm |
| 2-12. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 3. | 2414J1068 | [1] | COVER | |
| 4. | 2414N3938 | [1] | COVER | |
| 5. | 2414P4131 | [1] | COVER | |
| 6. | 2414P4130 | [1] | COVER | |
| 7. | 2416J825 | [1] | BRACKET | BRACKET |
| 8. | 2416J824 | [1] | BRACKET | BRACKET |
| 9. | 2420Z969 | [1] | KEY | KOB |
| 10. | 2420Z988 | [1] | GROMMET | GROMMET |
| 11. | 2416T9292 | [4] | CUSHION, RUBBER | |
| 12. | 2416T8283 | [4] | RUBBER SLEEVE | KOB |
| 13. | 2427R302 | [2] | HANDLE | KOB |
| 14. | 2427R302D2 | [2] | CATCH | KOB |
| 15. | ZS18C08025 | [16] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 16. | ZN18C08007 | [16] | NUT | KOBM08x1.25mm |
| 17. | ZW26X08000 | [16] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 16. | ZS18C12025 | [8] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 19. | ZS18C10025 | [20] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 20. | ZW26X10000 | [16] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 21. | 2418T5373C2 | [16] | WASHER | KOBID 11 x OD 30 x Th 3.20mm Superseded by part number: 2418T12346 |
| 22. | ZW16H12000 | [8] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 23. | 2416T13435 | [11] | RUBBER | KOB |
