神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (09-029) - VALVE ASSY, CONTROL/ P.N. 2436U1257F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
947 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1257F1 | [1] | VALVE, CONTROL CONSITS OF THE FOLLOWING PARTS | VALVE, CONTROL CONSITS OF THE FOLLOWING PARTS |
| 1. | 2436U1779S1 | [1] | HYDRAULIC VALVE | KOBSECTION ASSY,INLET |
| 2. | 2436U917S2 | [1] | SECTION ASSY, OUTLET | |
| 3. | 2436R740F1 | [1] | SPOOL | KOB |
| 4. | 2436R739F1 | [1] | SPOOL | KOB |
| 5. | 2436R738F1 | [1] | SPOOL | KOB |
| 6. | 2436R737F1 | [1] | SPOOL | KOB |
| 7. | 2436R736F1 | [1] | SPOOL | KOB |
| 8. | 2436Z280D1F1 | [3] | VALVE ASSY, RELIEF | VALVE ASSY, RELIEF |
| 9. | 2436R747F1 | [1] | VALVE PRESSURE RELIE | KOB |
| 10. | 2418Z836F1 | [2] | PLUG | KOB |
| 11. | 2436Z282F1 | [1] | X | KOB |
| 12. | 2436U1038S15 | [4] | CAM | CAM |
| 13. | 2436U917S9 | [4] | NUT | |
| 14. | 2436U1257S14 | [2] | ROD, TIE | ROD, TIE |
| 15. | 2436U917S11 | [2] | NUT | NUT |
| 16. | 2436U1257S16 | [1] | ROD, TIE | ROD, TIE |
| 17. | 2436U1812S12 | [11] | PLUG ASSY | |
| 18. | 2436R741F1 | [1] | SPACER | KOB |
| 19. | 2436R746F1 | [1] | VALVE | KOB Superseded by part number: 2436R936F1 |
| 20. | 2436U1256S18 | [8] | PLUG | |
| 21. | 2436U1256S19 | [1] | PLUG | |
| 22. | 2436U1256S20 | [1] | pLUG | |
| 23. | 2436U1256S21 | [2] | pLUG | |
| 24. | 2456R748F1 | [1] | VALVE ASSY, RELIEF | |
| 25. | 2436U1256S23 | [2] | PLUG | PLUG |
