神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (09-028) - VALVE ASSY, CONTROL/ P.N. 2436U1256F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
433 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1256F1 | [1] | CONTROL VALVE | KOBCONSITS OF THE FOLLOWING PARTS |
| 1. | 2436R1049F1 | [2] | SECTION ASSY, INLET | SECTION ASSY, INLET |
| 2. | 2418Z836F1 | [2] | PLUG | KOB |
| 3. | 2436R745F1 | [1] | SPOOL | KOB |
| 4. | 2436R744F1 | [1] | SPOOL | KOB |
| 5. | 2436R743F1 | [1] | SPOOL | KOB |
| 6. | 2436R742F1 | [1] | SPOOL ASSY | SPOOL ASSY |
| 7. | 2436R741F1 | [1] | SPACER | KOB |
| 8. | 2418Z723 | [1] | SPACER | |
| 9. | 2436Z280D1F1 | [2] | VALVE ASSY, RELIEF | VALVE ASSY, RELIEF |
| 10. | 2436U1038S15 | [1] | CAM | CAM |
| 11. | 2436U1256S11 | [1] | CAM | CAM |
| 12. | 2436U1812S12 | [7] | PLUG ASSY | |
| 13. | 2436R746F1 | [1] | VALVE | KOB Superseded by part number: 2436R936F1 |
| 14. | 2436U917S9 | [4] | NUT | |
| 15. | 2436U1256S15 | [2] | ROD, TIE | ROD, TIE |
| 16. | 2436U917S11 | [2] | NUT | NUT |
| 17. | 2436U1256S17 | [1] | ROD, TIE | ROD, TIE |
| 18. | 2436U1256S18 | [9] | PLUG | |
| 19. | 2436U1256S19 | [1] | PLUG | |
| 20. | 2436U1256S20 | [1] | PLUG | |
| 21. | 2436U1256S21 | [2] | PLUG | |
| 22. | 2436R747F1 | [2] | VALVE PRESSURE RELIE | KOB |
| 2 3. | 2436U1256S23 | [2] | PLUG | PLUG |
