| . . | 2436U1746F1. F2 | [1] | VALVE ASSY, PILOT CONSISTS OF THE FOLLOWING PARTS | |
| 101. | NNS | [1] | CASING | |
| 102. | NNS | [1] | CASING | |
| 151. | 2436U741S462 | [6] | PLUG | KOBPLUG |
| 201. | NNS | [4] | PLUG | |
| 210. | NNS | [4] | SEAL, PENTA | |
| 21 1. | NNS | [4] | SCRAPER | |
| 212. | ZD12002500 | [4] | O-RING | |
| 214. | NNS | [4] | ROD, PUSH | |
| 301. | NNS | [4] | SPOOL | |
| 310. | ZS23C04006 | [4] | SCREW,Hex Socket Head, M4 x 6mm | KOBM04x0.7x06mm |
| 311. | NNS | [4] | SEAT, SPRING | |
| 312. | NNS | [4] | WASHER | |
| 313. | NNS | [4] | WASHER | |
| 320. | NNS | [4] | SPRING, F1 ONLY | |
| 321. | NNS | [4] | SPRING, F2 ONLY | |
| 333. | NNS | [4] | SPRING | |
| 412. | NNS | [4] | BUSHING | |
| 413. | NNS | [2] | SHAFT | |
| 420. | NNS | [2] | PEDAL | |
| 421. | NNS | [4] | CAPSCREW | |
| 423. | NNS | [4] | CAPSCREW | |
| 427. | NNS | [4] | LOCKWASHER | |
| 431. | NNS | [2] | BUSHING | |
| 432. | NNS | [8] | CAPSCREW | |
| 433. | ZS16C10025 | [2] | SCREW | KOBM10x1.50x25mm Superseded by part number: ZS18C10025 |
| 434. | ZS16C10045 | [2] | SCREW | KOBM10x1.50x45mm Superseded by part number: ZS18C10045 |
| 435. | ZN16C10008 | [4] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 501. | 2436U1746S501 | [4] | BOOT | KOBCOVER BLO BOLT |
| 510. | 2436U1746S510 | [3] | BOLT | |
| 511. | ZN16C08007 | [6] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 521. | ZD12P01200 | [4] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 522. | 2436U1746S522 | [1] | SPACER | |
| . . | 2436U1746R10 | [1] | PILOT VALVE | KOBREF 101, 151, 201, 210 TO 212, 214, 301, 310 TO 313, 320, 335, 412 & 421 Superseded by part number: 2436U1746R20 |
| . . | 2436U17 46R20 | [1] | REPAIR KIT REF 102, 151, 201, 210 TO 212, 214, 301, 310 TO 313, 320, 335, 442 & 421 | |
| . . | 2436U1746R30 | [1] | REPAIR KIT REF 413, 420, 421, 423, 427, 431 & 432 | REPAIR KIT REF 413, 420, 421, 423, 427, 431 & 432 |
| . . | 2436U1746R40 | [1] | REPAIR KIT REF 101, 151, 201, 210 TO 212, 214, 301, 310 TO 313, 321, 335, 412 & 421 | REPAIR KIT REF 101, 151, 201, 210 TO 212, 214, 301, 310 TO 313, 321, 335, 412 & 421 |
| . . | 2436U1746R50 | [1] | REPAIR KIT REF 102, 151, 201 , 210 TO 214, 301, 310 TO 313, 321, 335, 412 & 421 | REPAIR KIT REF 102, 151, 201 , 210 TO 214, 301, 310 TO 313, 321, 335, 412 & 421 |
