凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (05-007) - MOUNT GROUP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
481 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86511674
|
[4] |
BOLT,Hex, M20 x 120mm, Cl 10.9
|
PLO
Superseded by part number: 86639035
|
| 2. |
86639847
|
[16] |
WASHER,21.8mm ID x 44.5mm OD x 5mm Thk
|
RAC
|
| 3. |
86986163
|
[4] |
SPACER
|
BN
Rear Mount, Flex
|
| 4. |
264031
|
[8] |
NUT,M20 x 2.5, Cl 10
|
BER
|
| 5. |
87266921
|
[2] |
SLIDE
|
BN
Body Mount
|
| 7. |
BN50779
|
[6] |
BOLT,5/16"-18 X 1.00", EH, DOR
|
BN
|
| 8. |
BN312850
|
[4] |
SPRING
|
BN
1" ID x 4" Lg-Die
|
| 10. |
BN313899
|
[4] |
LINKAGE
|
BN
5/8-11 Top, Grade 8, PL
|
| 11. |
BN247111
|
[8] |
WASHER
|
BN
5/8, G8
|
| 12. |
280233
|
[4] |
BOLT,Hex, 5/8" - 11 x 2 1/2", Gr 8
|
BHB
|
| 13. |
BN313867
|
[2] |
BELT,4.00" W x 153.00" L
|
BN
|
| 14. |
BN313897
|
[2] |
Adhesive, 5 Oz. Tube
|
|
| 15. |
BN55361
|
[6] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 16. |
86986785
|
[2] |
SPACER
|
BN
Rear Mount, Flex-Air
|
| 17. |
84334022
|
[4] |
BOLT,Hex, M20 x 2.5 x 180mm, Cl 10.9
|
ZED
|
