凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (05-006) - EXTENSION GROUP, 70’, 46” Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
190 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN320783
|
[1] |
EXTENSION
|
BN
46"
|
| 2. |
343765A1
|
[1] |
SUPPORT TUBE
|
BN
tube RH
|
| 3. |
343774A1
|
[1] |
SUPPORT TUBE
|
TYR
tube LH
|
| 4. |
87267710
|
[1] |
BRACKET
|
TYR
46" Extension, 60-70' Boom, LH
|
| 5. |
87267711
|
[1] |
BRACKET
|
TYR
46" Extension, 60-70' Boom, RH
|
| 9. |
BN50595
|
[4] |
WASHER,1/2", Stainless
|
BN
|
| 10. |
BN50593
|
[4] |
BOLT,1/2"-13 x 1-1/2", Stainless Steel
|
BN
|
| 11. |
BN55363
|
[4] |
LOCK NUT,1/2"-13, Nylon, Stainless
|
BN
|
| 15. |
86639847
|
[12] |
WASHER,21.8mm ID x 44.5mm OD x 5mm Thk
|
RAC
|
| 16. |
264031
|
[6] |
NUT,M20 x 2.5, Cl 10
|
BER
|
| 17. |
86639154
|
[6] |
BOLT,Hex, M20 x 65mm, Cl 10.9
|
FAR
|
| 18. |
BN50146
|
[16] |
WASHER,3/8", Stainless
|
BN
|
| 19. |
BN50759
|
[8] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 20. |
BN50254
|
[8] |
BOLT,3/8"-16 x 1", Stainless
|
BN
|
| 22. |
311863A1
|
[3] |
REFLECTOR
|
CAS
Retroreflective Red
|
| 23. |
311865A1
|
[3] |
REFLECTOR
|
CAS
fluorescent orange
|
