神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (09-034) - REGULATOR ASSY/ P.N. 2436U1845F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
996 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1845F1 | [1] | REGULATOR | KOBCONSITS OF THE FOLLOWING PARTS |
| 1. | 2436U1848F1 | [1] | VALVE | KOBSEE FIGURE (C.P.M.) |
| 2. | 2436U1695F1 | [1] | X | KOB |
| 5. | 2438U1845S5 | [1] | COVER | |
| 6. | 2436U1691S6 | [1] | COVER | |
| 7. | 2436U1691S7 | [1] | PISTON | KOB |
| 8. | 2436U1691S8 | [1] | SPOOL | KOB |
| 9. | 2436U1691S9 | [1] | BUSHING | KOB |
| 10. | 2436U1845S10 | [1] | PLUG | |
| 11. | 2436U1691S11 | [1] | POPPET | KOB |
| 12. | 2436U1691S12 | [1] | RETAINER | KOB |
| 13. | 2436U1691S13 | [1] | BUSHING | KOB |
| 14. | 2436U1691S14 | [1] | PLUG | KOB |
| 15. | 2436U1691S15 | [1] | SPRING | KOB |
| 16. | 2441U399S84 | [1] | FILTER | FILTER |
| 18. | 2436U1691S18 | [1] | O-RING | KOB |
| 19. | 2436U1691S19 | [1] | O-RING | KOB |
| 20. | 2436U1691S20 | [1] | O-RING | KOB |
| 21. | 2436U1691S21 | [1] | O-RING | KOB |
| 22. | ZD12P00900 | [1] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 23. | 2436U1691S23 | [4] | SCREW | KOB |
| 24. | ZS23C06040 | [2] | SCREW,Hex Socket Head, M6 x 40mm | KOBM06x1.0x40mm |
| 25. | ZW22K10000 | [4] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 26. | ZW22K06000 | [2] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 27. | ZR16X01200 | [1] | RING | KOBRetaining -- ID 11.1 x OD 12 x Th 1.0mm |
| 28. | 2456U1091S28 | [1] | BALL | |
| 29. | 2456U1091S29 | [1] | PLUG | |
| 30. | 2456U1091S30 | [1] | PLUG | |
| 31. | 2456U1091S31 | [2] | PLUG | |
| 32. | 2456U1091S32 | [1] | PACKING | |
| 33. | 2456U1091S33 | [9] | PLUG | |
| 34. | 2456U1091S34 | [1] | ORIFICE | |
| 35. | 24100U448S12 | [1] | PLUG | KOB |
