神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (09-036) - REGULATOR ASSY/ P.N. 2436U1847F1-F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
425 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1847F1, F2 | [1] | REGULATOR ASSY CONSITS OF THE FOLLOWING PARTS | |
| 1. | 2436U1849F1 | [1] | VALVE ASSY, SEE FIGURE (C.P.M.) F1 ONLY | |
| 5. | 2436U1847S5 | [1] | COVER, F1 ONLY | |
| 6. | 2436U1693S6 | [1] | COVER | |
| 7. | 2436U1693S7 | [1] | PISTON | |
| 8. | 2436U1693S8 | [1] | SPOOL | SPOOL |
| 9. | 2436U1693S9 | [1] | BUSHING | |
| 10. | 2436U1845S10 | [1] | PLUG | |
| 11. | 2436U1691S11 | [1] | POPPET | KOB |
| 12. | 2436U1691S12 | [1] | RETAINER | KOB |
| 13. | 2436U1691S13 | [1] | BUSHING | KOB |
| 14. | 2436U1691S14 | [1] | PLUG | KOB |
| 15. | 2436U1691S15 | [1] | SPRING | KOB |
| 16. | 2441U399S84 | [1] | FILTER | FILTER |
| 18. | 2436U1693S18 | [2] | O-RING | O-RING |
| 20. | 2436U1693S20 | [1] | O-RING | KOB |
| 21. | 2436U1691S21 | [1] | O-RING | KOB |
| 22. | ZD12P00900 | [1] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 23. | ZS23C10110 | [4] | SCREW,Hex Socket Head, M10 x 110mm | KOBM10x1.50x110mm |
| 24. | ZS23C06035 | [2] | SCREW,Hex Socket Head, M6 x 35mm | KOBM06x1.0x35mm |
| 25. | ZW22K10000 | [4] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 26. | ZW22K06000 | [2] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 27. | ZR16X01200 | [1] | RING | KOBRetaining -- ID 11.1 x OD 12 x Th 1.0mm |
| 28. | 2436U1691S28 | [1] | BALL | KOB |
| 29. | 2436U1691S29 | [1] | PLUG | KOB |
| 30. | 2436U1691S30 | [1] | PLUG | |
| 31. | 2436U1691S31 | [8] | PLUG | |
| 32. | 2436U1691S32 | [1] | PACKING | KOB |
| 33. | 2436U1691S33 | [8] | PLUG | KOB |
| 34. | 2436U1691S34 | [1] | ORIFICE | ORIFICE |
| 35. | 24100U448S12 | [1] | PLUG | KOB |
| 36. | 2436U1849F2 | [1] | X | KOBSEE FIGURE (C.P.M) F2 ONLY |
| 37. | 2436U1847S37 | [1] | COVER, F2 ONLY | |
