神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (09-047) - CYLINDER ASSY, BUCKET/ P.N. 2438U664F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
587 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U664F1 | [1] | BRACKET | KOBCONSITS OF THE FOLLOWING PARTS |
| 1. | 2438U664S1 | [1] | TUBE | KOB |
| 2. | 2438U664S2 | [2] | BUSHING | KOB Superseded by part number: 2438U324S36 |
| 3. | 2445R138D9 | [4] | SEAL,100mm ID x 120mm OD x 4mm Thk | KOBDust -- ID 100 x OD 120 x Th 4mm |
| 4. | 2438U664S4 | [1] | PISTON ROD | KOB |
| 5. | 2438U664S5 | [1] | PISTON | KOB |
| 6. | ZD12G11500 | [1] | O-RING,114.40mm ID x 120.60mm OD x 3.10mm | KOBID 114.40 ± 0.94 x OD 120mm |
| 7. | ZD75G11500 | [2] | BACK-UP RING | KOB |
| 8. | R45P0049D5 | [1] | SEAL | KOB |
| 9. | 45Z91D113 | [1] | O-RING | KOBID 149.00 ± 0.58 OD 162.20mm |
| 10. | R45T0014D8 | [4] | WEAR RING | KOB |
| 11. | 2438U664S11 | [1] | NUT | KOB |
| 12. | 2438U664S12 | [1] | WEAR RING | KOB |
| 13. | 2438U664S13 | [1] | PLATE | KOB |
| 14. | 2438U664S14 | [1] | PLATE | KOB |
| 15. | 2438U664S15 | [1] | SPRING SPRING | SPRING SPRING |
| 16. | 2438U324S13 | [1] | SPRING | KOBSPRING |
| 17. | 2438U1308S16 | [1] | RING | RING |
| 18. | 2438U664S18 | [1] | COVER | |
| 19. | 2438U324S32 | [1] | O-RING | KOB |
| 20. | ZD12G16000 | [2] | O-RING,159.30mm ID x 170.70mm OD x 5.70mm | KOB |
| 21. | 2445R216D22 | [2] | RING, BACK-UP | RING, BACK-UP |
| 22. | 2438U324S15 | [1] | BUSHING | KOB |
| 23. | 2438U323S22 | [1] | CLIP | KOB |
| 24. | R45P0050D4 | [1] | SEAL | KOB |
| 25. | R45P0051D7 | [1] | O-RING | KOB |
| 26. | 2438U352S10 | [1] | KIT | KOB Superseded by part number: 2418U130D27 |
| 27. | 2438U664S27 | [1] | SEAL, DUST | |
| 28. | 2438U333S19 | [1] | CLIP | KOB Superseded by part number: 2438U1260S13 |
| 29. | ZS23C16070 | [16] | SCREW,Hex Socket Head, M16 x 70mm | KOBM16x2.0x70mm |
| . . | 2438U664R100 | [1] | REPAIR KIT | KOBREPAIR KIT CONSISTS OF REF 19, 20, 21, 24, 25, 26, & 27 |
| . . | 2438R664R110 | [1] | REPAIR KIT CONSISTS OF REF 6 - 10 | |
