神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (09-054[01]) - PUMP ASSY, HYDRAULIC Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
747 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U720F1, F2 | [1] | PUMP ASSY, HYDRAULIC CONSISTS OF THE FOLLOWING PARTS | |
| 3. | 2441U658S7 | [1] | PLATE, VALVE | PLATE, VALVE |
| 4. | 2441U658S1 | [1] | HOUSING | KOB |
| 5. | 2441U658S2 | [1] | PLUG | |
| 6. | 2441U658S3 | [2] | PLUG | PLUG |
| 7. | 2441U658S4 | [2] | NUT | KOB |
| 8. | ZD11P01600 | [2] | O-RING | KOBID 15.80 ± 0.20 x OD 20.6mm |
| 9. | ZS73C12060 | [2] | BOLT | KOB |
| 11. | 2441U720S11 | [1] | SHAFT | KOB |
| 12. | 2441U658S8 | [1] | BLOCK | KOB |
| 13. | 2441U658S11 | [1] | PIN | PIN |
| 14. | 2441U658S9 | [7] | NOT SERVICED | KOB |
| 15. | 24100U607S21 | [1] | RETAINER | KOB |
| 16. | 2441U658S12 | [1] | PLATE | KOB |
| 17. | 2441U658S13 | [1] | RETAINER | RETAINER |
| 18. | 2441U658S14 | [4] | SPRING | KOB |
| 19. | 244100U607S13 | [1] | PIECE | |
| 20. | 24100U607S23 | [1] | CASE | CASE |
| 21. | 2441U658S17 | [1] | SPACER | KOBPIECE |
| 22. | 24100U607S9 | [2] | SPRING | KOB |
| 23. | 2441U658S18 | [1] | SNAP RING | KOBRETAINER |
| 24. | ZR16X07000 | [1] | RING | KOBRETAINER |
| 25. | 2441U658S20 | [1] | O-RING | KOB |
| 26. | 2441U658S21 | [1] | OIL SEAL | KOB Superseded by part number: 2441U186S17 |
| 27. | 24100U607S10 | [1] | BEARING | KOB Superseded by part number: 26794770 |
| 28. | 2441U658S23 | [2] | BALL BEARING | KOB |
| 29. | 2441U658S25 | [14] | SCREW | KOB |
| 30. | 2441U658S26 | [1] | KEY | KOB |
| 31. | 2441U658S27 | [2] | SHIM | KOB |
| 32. | 2441U658S28 | [1] | SHIM | KOB |
| 33. | 2441U658S29 | [1] | SHIM | KOB |
| 34. | 2441U658S30 | [1] | SHIM | SHIM |
| 35. | 2441U658S31 | [1] | SHIM | SHIM |
| 36. | 2435U184531 | [1] | REGULATOR ASSY, F1 ONLY | |
| 37. | 2436U1846F1 | [1] | REGULATOR | KOBSEE FIGURE (C.P.M) F2 ONLY |
| 38. | 2441U720S38 | [1] | BODY | BODY |
| 39. | 2441U658S33 | [1] | PACKING | PACKING |
| 4 0. | 2441U658S34 | [1] | PLUNGER | KOB |
| 41. | 2441U658S35 | [1] | ROD | ROD |
| 42. | 2441U720S42 | [1] | ROD | KOB |
| 43. | 2441U658S37 | [2] | SPRING | SPRING |
| 44. | 2441U658S38 | [1] | RETAINER | KOB |
| 45. | 2441U658S39 | [1] | RETAINER | RETAINER |
| 46. | 2441U658S40 | [1] | RING PIECE | RING PIECE |
| 47. | 2441U658S41 | [1] | SETSCREW | |
| 48. | 2441U720S48 | [1] | PLUG | |
| 49. | 2441U720S49 | [2] | PLUG | KOB |
| 50. | ZS23C16045 | [6] | CAP,Hex Socket Head, M16 x 45mm | KOBScrew -- M16x2.0x45mm |
| 51. | ZW22K16000 | [6] | LOCK WASHER | KOBID 16 x OD 24 x Th 3.5mm |
| 52. | 2441U658S46 | [2] | PIN | PIN |
| 53. | ZR16X01000 | [1] | SEAL RETAINER | KOB |
| 54. | ZS83C12016 | [1] | SETSCREW | |
| 55. | 24100U448S12 | [1] | PLUG | KOB |
| 56. | 2441U1691S29 | [1] | PLUG | |
| 57. | 24100U448S16 | [3] | PLUG | KOB |
| 58. | 2441U658S42 | [1] | RETAINER | KOB |
| 59. | 2441U658S43 | [2] | BUSHING | KOB |
| 61. | 2441U658S52 | [1] | MANIFOLD | MANIFOLD |
| 62. | 2441U658S53 | [1] | BUSHING | |
| 63. | 2441U658S54 | [1] | RETAINER | KOB |
| 64. | 2436U1691S12 | [1] | RETAINER | KOB |
| 65. | 2441U658S56 | [1] | SPRING | SPRING |
| 66. | 2441U658S57 | [1] | SPRING | SPRING |
| 67. | 2441U720S67 | [1] | PLUG | |
| 68. | 2436U1692S8 | [1] | NUT | |
| 69. | 2441U720S69 | [1] | SETSCREW | |
| 70. | 2441U720S70 | [1] | O-RING | KOB |
| 71. | 24100U448S12 | [1] | PLUG | KOB |
| . . | 2441U720R100 | [1] | ROTOR DISTRIBUTOR | KOBREPAIR KIT CONSISTS OF REF 11 - 35 |
| . . | 2441U720R110 | [1] | MANIFOLD | KOBREPAIR KIT CONSISTS OF REF 61 - 71 |
