| . . | 24100J6533F3 | [1] | REMOTE-CONTROL ASSY | |
| 1. | 2436U944F13 | [2] | PILOT VALVE | KOBSEE FIGURE (C.P.M.) |
| 2. | 2436U1746F2 | [1] | PILOT VALVE | KOBSEE FIGURE (C.P.M.) |
| 4. | 2436U1892F1 | [1] | VALVE ASSY, CONTROL SHUTTEL SEE FIGURE (C.P.M.) | VALVE ASSY, CONTROL SHUTTEL SEE FIGURE (C.P.M.) |
| 5. | 2436U1891F1 | [1] | VALVE ASSY, CONTROL SHUTTEL SEE FIGURE (C.P.M.) | VALVE ASSY, CONTROL SHUTTEL SEE FIGURE (C.P.M.) |
| 6. | 2416P10230 | [1] | BLOCK | BLOCK |
| 7. | 2416P10231 | [1] | BLOCK | BLOCK |
| 8. | 2436U1747F1 | [1] | VALVE PRESSURE RELIE | KOBSEE FIGURE (C.P.M.) |
| 9. | 2444T3280 | [2] | TEE | KOBCONNECTOR |
| 10. | 2444Z2721 | [2] | CONNECTOR | |
| 1 1. | ZH22F06000 | [2] | CONNECTION | KOB |
| 12. | 2444P1171D1 | [2] | CONNECTOR | CONNECTOR |
| 13. | 2444P1171D2 | [2] | CONNECTOR | |
| 14. | 2444T2245 | [1] | CONNECTOR | CONNECTOR |
| 15. | 2444Z2726 | [45] | HYD CONNECTOR | KOB |
| 16. | 2420R349D320 | [1] | HOSE ASSY. | KOB3200mm Long (126 in) |
| 17. | ZH22X04000 | [8] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 18. | ZH22X08000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 19. | ZH22X12000 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) |
| 20. | ZH21M08004 | [6] | HYD CONNECTOR | KOBCONNECTOR |
| 22. | ZH21M08006 | [3] | HYD CONNECTOR | KOBCONNECTOR |
| 23. | ZE72X04000 | [14] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 24. | ZE72X12000 | [1] | PLUG | KOB(3/4" PF) (Incls. O-Ring ZD12P02400) |
| 25. | 2444T3290 | [5] | ELBOW | KOB Superseded by part number: 2444Z2338 |
| 26. | 2420R564 | [2] | GROMMET | KOB |
| 28. | ZH32X06000 | [1 1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 29. | ZH32X06008 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB90° -- 3/8"PFx1/2"PFx40mm Long (Same as ZD12P02400) |
| 30. | ZH52F06000 | [2] | TEE | TEE |
| 31. | 2444T3176 | [2] | TEE | TEE |
| 32. | ZH31M08004 | [2] | ELBOW | KOB |
| 33. | 2444T3309 | [6] | TEE | KOB(2) 3/8" PF x 1/4" PF x 60mm Long (Incls. O-Ring ZD12P01100) |
| 34. | ZH31M08006 | [3] | ELBOW | KOB |
| 35. | ZH51K08000 | [6] | TEE | KOB |
| 36. | ZD12P01100 | [5] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 37. | 2418P14329 | [1] | TUBE | TUBE |
| 38. | ZH32X04000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 39. | ZD12P02600 | [1] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 40. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 41. | R18P0168D62 | [1] | HOSE | HOSE |
| 42. | 2420R537D050 | [2] | HOSE,9.53mm ID x 500mm L | KOB |
| 43. | 2420R537D030 | [2] | HOSE,9.53mm ID x 300mm L | KOB |
| 44. | 2420R537D070 | [3] | HOSE,9.60mm ID x 700mm L | KOB700mm Long (27-1/2 in) |
| 45. | 2420R537D058 | [2] | HOSE,9.60mm ID x 580mm L | KOB Superseded by part number: 2420R537D060 |
| 46. | 2420R537D080 | [1] | HOSE,9.60mm ID x 800mm L | KOB |
| 48. | 2420R537D200 | [3] | HOSE,9.60mm ID x 2000mm L | KOB |
| 49. | 2420R537D250 | [7] | HOSE ASSY.,9.60mm ID x 2500mm L | KOB2500mm Long (98-27/64 in) |
| 50. | 2420R537D270 | [1] | FLEXIBLE HOSE,9.60mm ID x 2700mm L | KOB2700mm Long (106-19/64 in) |
| 51. | 2420R537D283 | [1] | HOSE | HOSE |
| 52. | 2420R537D276 | [1] | HOSE,9.60mm ID x 2760mm L | KOB Superseded by part number: HX21E06276DX |
| 53. | 2420R537D358 | [2] | TUBE,9.60mm ID x 3580mm L | KOB Superseded by part number: HX21E06358DX |
| 54. | 2420R537D363 | [2] | HOSE | HOSE |
| 55. | 2420R537D100 | [3] | HOSE,9.60mm ID x 1000mm L | KOB |
| 56. | 2420R537D409 | [2] | HOSE | HOSE |
| 57. | 2420R537D405 | [2] | HOSE HOSE YS. 0119 to YS. 0128 | HOSE HOSE YS. 0119 to YS. 0128 |
| 59. | 2420R537D397 | [1] | HOSE,9.60mm ID x 3970mm L | KOBYS., Start Serial: 0119 Superseded by part number: HX21E06397DX |
| 60. | 2420R537D400 | [1] | TUBE,9.60mm ID x 4000mm L | KOB4000mm Long (157-31/64 in) |
| 61. | 2420R349D443 | [1] | HOSE | HOSE |
| 62. | 2420R349D560 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: HX21E04560DX |
| 63. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB |
| 64. | 2420R537D052 | [2] | HOSE,9.60mm ID x 520mm L | KOB Superseded by part number: 2420R537D055 |
| 65. | 2420R349D500 | [1] | HOSE | HOSE |
| 66. | ZX33M06115 | [1] | HOSE ASSY | HOSE ASSY |
| 67. | ZX21M08240 | [1] | HOSE ASSY 2400mm Long (94-1/2 in) | HOSE ASSY 2400mm Long (94-1/2 in) |
| 68. | ZX31M12250 | [1] | HOSE | KOBHOSE, HYDR 2500mm Long (98-7/16 in) |
| 69. | ZX15K08025 | [5] | KIT | KOBNYLON |
| 71. | ZX15K08060 | [1] | TUBE | KOBN2 |
| 72. | ZX15K08270 | [1] | TUBE | KOBN2 |
| 74. | ZX15K08150 | [1] | TUBE | KOB |
| 75. | ZX15K08230 | [1] | TUBE | KOB |
| 76. | ZX15K08260 | [1] | TUBE | KOB |
| 77. | 2432T3144D1 | [2] | CLAMP | CLAMP |
| 78. | ZC15X03300 | [4] | CLIP | KOB |
| 79. | 2432Z290D4 | [20] | CLIP Wire Ties -- 365mm Long | CLIP Wire Ties -- 365mm Long |
| 80. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 81. | ZS18C10070 | [2] | SCREW,Hex, M10 x 70mm | KOBM10x1.50x70mm |
| 82. | 2420N458D10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm Superseded by part number: ZS28C10030 |
| 83. | 2420N458D08045 | [4] | CAPSCREW | CAPSCREW |
| 84. | 2420N458D08040 | [4] | CAPSCREW | CAPSCREW |
| 85. | 2420N458D06030 | [4] | SCREW,Hex Socket Head, M6 x 30mm | KOB Superseded by part number: ZS28C06030 |
| 86. | ZW26X10000 | [11] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 87. | ZW26K10000 | [4] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
| 88. | ZW26K08000 | [8] | LOCK WASHER | KOBID 08 x OD 13 x Th 2.0mm |
| 89. | ZW26K06000 | [18] | LOCK WASHER | KOBID 06 x OD 11 x Th 1.5mm |
| 90. | 2444T3288 | [8] | 45 ELBOW | KOB45° -- (Incls. O-Ring ZD12P01100) |
| 91. | ZC45X46014 | [2] | CLIP | KOBID 46mm Single Cable Superseded by part number: ZC46X46014 |
| 92. | ZW16X10000 | [5] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 93. | ZN18C10008 | [5] | NUT | KOBM10x1.50mm |
| 94. | ZC45X50014 | [3] | CLIP | CLIP |
| 95. | 2420R537D064 | [3] | HOSE | HOSE |
| 96. | 2420R537D071 | [2] | HOSE | HOSE |
| 97. | 2420R537D075 | [2] | HOSE,9.60mm ID x 750mm L | KOB |
| 98. | 2420R537D210 | [2] | HOSE,9.53mm ID x 2100mm L | KOB |
| 99. | ZS18C06040 | [2] | SCREW,Hex, M6 x 40mm | KOBM06x1.0x40mm |
| 100. | ZX21M08006 | [1] | HOSE | |
| 101. | ZH22X04006 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| 102. | 2444Z2734 | [3] | TEE | TEE |
| 103. | ZH32X08000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 104. | ZH22X06000 | [10] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 105. | ZE72X06000 | [4] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 106. | ZN18C06005 | [6] | NUT | KOBM06x1.0mm |
| 107. | 2418R312D2 | [2] | PLATE | KOB |
| 108. | 2436U989D3FI | [2] | VALVE, SOLENOID SEE FIGURE (C.P.M.) | |
| 109. | 2420R537D335 | [2] | FLEXIBLE HOSE,9.60mm ID x 3350mm L | KOB Superseded by part number: HX21E06335DX |
| 110. | 24 20R537D370 | [1] | HOSE | |
| 111. | 2420R537D260 | [5] | HOSE,9.60mm ID x 2600mm L | KOB |
| 112. | ZS18C08020 | [11] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 113. | ZW26X08000 | [11] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 1 14. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 116. | 2444T3294 | [1] | CONNECTOR | CONNECTOR |
| 117. | 2418T15127 | [4] | SPACER | SPACER |
| 118. | 2416T17191 | [2] | RUBBER | RUBBER |
| 119. | 2420N458D06020 | [14] | SCREW,Hex Socket Head, M6 x 20mm | KOB Superseded by part number: ZS28C06020 |
| 120. | 2432N578 | [1] | PLATE | KOB |
| 125. | 24100P1948F2 | [1] | SWITCH ASSY | KOB |
| 126. | ZG22U06004 | [1] | HYD CONNECTOR | KOBSOCKET |
| 127. | ZS31C06014 | [2] | SCREW,Phillips Drive, Pan HD, M6 x 14mm | KOBM06x1.0x14mm |
| 128. | ZH32Z04000 | [1] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 129. | 2436R1125F1 | [1] | VALVE, SHUTTLE SEE FIGURE (C.P.M.) | VALVE, SHUTTLE SEE FIGURE (C.P.M.) |
| 130. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 136. | 2420R349D370 | [1] | HOSE,3700.00 mm | KOB Superseded by part number: HX21E04370DX |
| 137. | 2420R349D290 | [1] | HYDRAULIC HOSE,6.35 mm ID x 2900.00 mm | KOB |
| 142. | ZH22F04000 | [2] | HYD CONNECTOR | KOB |
| 143. | ZH22F06000 | [2] | CONNECTION | KOB |
| 150. | ZX15K08070 | [1] | FLEXIBLE HOSE | KOB |
| 151. | ZX15K08015 | [1] | KIT | KOBNYLON |
| 152. | ZX15K08028 | [1] | TUBE, N2 NYLON | TUBE, N2 NYLON |
| 153. | ZX15K08036 | [1] | TUBE, NYLON | |
| 154. | ZX15K08140 | [1] | TUBE, NYLON | TUBE, NYLON |
| 155. | ZX15K08090 | [1] | FLEXIBLE HOSE | KOB |
| 156. | ZX15K08065 | [1] | TUBE | KOB |
| 157. | ZX15K08011 | [1] | TUBE,N2 NYLON | TUBE,N2 NYLON |
| 158. | ZX15K08080 | [1] | TUBE, NYLON | TUBE, NYLON |
