神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (03-003) - WIRING ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
550 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1707F1 | [1] | WIRING ASSY | |
| 1. | 2479U229 | [1] | RELAY | KOB |
| 2. | 2479Z855 | [1] | SWITCH | KOB |
| 3. | 2479Z1067 | [1] | HARNESS | |
| 4. | 2479Z1066 | [1] | HARNESS | |
| 5. | 2479Z977 | [1] | HARNESS | KOB |
| 6. | ZS31C06012 | [1] | SCREW,Phillips Drive, Pan HD, M6 x 12mm | KOBM06x1.0x12mm |
| 7. | ZW16K06000 | [1] | WASHER | KOBID 06 x OD 11.5 x Th 1.6mm |
| 8. | ZW26X06000 | [1] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
