| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U752F1 | [1] | PUMP ASSY, HYDRAULIC | |
| 1. | 2453U451F2 | [1] | REDUCER | KOB |
| 2. | 2418U189F1 | [1] | TUBE ASSY, SEE FIGURE 05-005 | |
| 3. | 2441U720F1 | [1] | HYDRAULIC PUMP | KOBSEE FIGURE 05-005 |
| 4. | 2441U720F2 | [1] | HYDRAULIC PUMP | KOB |
| 5. | 2441U721F2 | [1] | HYDRAULIC PUMP | KOBHYDRAULIC |
| 6. | 2441U660F2 | [1] | PUMP | KOB |
| 7. | 2446U297F1 | [1] | FILTER ASSY | KOB |
| 7-1. | 2446U297S1 | [1] | BASE | |
| 7-2. | 2446R204F1 | [1] | FILTER | KOBBASE |
| 7-2 A. | 2446R204S1 | [1] | HEAD | KOB |
| 7-2B. | 2446R204S2 | [1] | HYDRAULIC VALVE | KOBBY-PASS |
| 7-2C. | 2446R204S3 | [1] | ELEMENT | KOB Superseded by part number: 2446R170S3 |
| 7-2D. | ZD11P09500 | [1] | O-RING | KOBID 94.6 ± 0.81 x OD 105mm |
| 7-2E. | ZD75P09500 | [1] | BACK-UP RING | KOB |
| 7-2F. | 2446R204S6 | [1] | CASE | |
| 7-3. | ZS23C10095 | [2] | SCREW,Hex Socket Head, M10 x 95mm | KOBM10x1.50x95mm |
| 7-4. | ZW11K10000 | [2] | WASHER | KOBID 10 x OD 18 x Th 2.0mm |
| 8. | 2418U190F1 | [1] | COUPLING | KOBASSY |
| 8-1. | 2418U190S1 | [4] | SPIDER | KOB Superseded by part number: 2453U147S40M |
| 8-2. | 2418U190S2 | [4] | INSERT | KOB |
| 8-3. | 2418U190S3 | [4] | INSERT | KOB |
| 8-4. | 2418U190S4 | [4] | SCREW | KOB |
| 8-5. | 2418U190S5 | [4] | SCREW | KOB |
| 8-6. | ZS73C20030 | [2] | SETSCREW | SETSCREW |
| 8-7. | 2418U1 9037 | [1] | HUB | |
| 8-8. | ZP26008016 | [8] | PIN, SPRING | |
| 8-9. | 2418U190S9 | [4] | ELEMENT | KOB |
| 9. | 2441U443S8 | [2] | PACKING | KOB Superseded by part number: 2441U226S19 |
| 10. | 2441U443S7 | [1] | PACKING | KOB Superseded by part number: 2441U226S20 |
| 11. | 2441U443S9 | [1] | PACKING | KOB |
| 12. | ZS23C16055 | [8] | SCREW,Hex Socket Head, M16 x 55mm | KOBM16x2.0x55mm |
| 13. | ZS23C16050 | [2] | CAPSCREW,Hex Socket Head, M16 x 50mm | KOBSCREW M16x2.0x50mm |
| 14. | ZS23C16090 | [2] | SCREW,Hex Socket Head, M16 x 90mm | KOBM16x2.0x90mm |
| 15. | 2436U1691S23 | [2] | SCREW | KOB |
| 16. | ZW22K16000 | [12] | LOCK WASHER | KOBID 16 x OD 24 x Th 3.5mm |
| 17. | ZW22K10000 | [2] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
