神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (05-004) - TUBE ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
956 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2418U189F1 | [1] | TUBE ASSY | |
| 1. | 2418U174S1 | [1] | HOSE | KOBHOSE, RUBBER |
| 2. | 2418U189S2 | [1] | HOSE | KOBHOSE, RUBBER |
| 3. | 2418U189S3 | [1] | HOSE | KOBHOSE, RUBBER |
| 4. | 2418U189S4 | [1] | HOSE | KOBHOSE, RUBBER |
| 5. | 2418U189S5 | [1] | HOSE HOSE, RUBBER | HOSE HOSE, RUBBER |
| 6. | 2418U189S6 | [1] | HOSE | KOBHOSE, RUBBER |
| 7. | 2418U189S7 | [1] | HOSE | KOBHOSE, RUBBER |
| 8. | 2418U189S8 | [1] | HOSE | KOBHOSE, RUBBER |
| 9. | 2418U174S9 | [11] | HYD CONNECTOR | KOBCONNECTOR |
| 10. | 2418U174S21 | [7] | CONNECTOR CONNECTOR | CONNECTOR CONNECTOR |
| 1 1. | 2418U174S11 | [16] | PACKING PACKING | PACKING PACKING |
| 12. | 2418U174S12 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 13. | ZD11P02900 | [1] | O-RING | KOBO-RING |
| 14. | 2418U174S14 | [1] | FLANGE | KOB Superseded by part number: ZE12X12000 |
| 15. | 2418U174S15 | [1] | O-RING | KOB |
| 16. | ZS23C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm Superseded by part number: ZS28C10030 |
| 17. | ZW22K10000 | [4] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 29. | 2418U189S29 | [1] | HOSE | KOBHOSE, RUBBER |
| 30. | 2418U189S30 | [7] | CLAMP CLAMP | CLAMP CLAMP |
| 31. | 2418U189S31 | [1] | HOSE | HOSE |
