凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (12-012) - TANK & CRADLE GROUP, PRESSURE WASHER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
587 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN311561
|
[1] |
TANK
|
BN
Poly, 65 Gallon Superseded by part number: 87653336
|
| . . |
87266426
|
[1] |
COVER
|
BN
Tank, Pressure Washer
|
| 2. |
BN312120
|
[2] |
STRAP
|
TYR
65 Gallon Tank
|
| 3. |
BN320719
|
[1] |
SUPPORT
|
TYR
Cradle, 65 Gallon Tank
|
| 4. |
BN312121
|
[1] |
MOUNTING PLATE
|
BN
Water Valve
|
| 5. |
BN53817
|
[1] |
DRAIN VALVE
|
BN
Plastic, 1/2" NPT
|
| 6. |
BN320735
|
[1] |
SUPPORT
|
BN
Pressure Washer, LH
|
| 7. |
BN320734
|
[1] |
SUPPORT
|
TYR
Pressure Washer, RH
|
| 8. |
BN50759
|
[12] |
LOCK NUT,3/8"-16, Nylon, Stainless
|
BN
|
| 9. |
BN50146
|
[4] |
WASHER,3/8", Stainless
|
BN
|
| 10. |
BN50258
|
[8] |
BOLT,3/8"-16 X 1.25", Stainless
|
BN
|
| 11. |
BN50671
|
[2] |
BOLT,1/4"-20 x 1.00", Stainless Steel
|
BN
|
| 12. |
BN73561
|
[2] |
FITTING
|
BN
Barb, 3/4 NPT X 3/4 HS Superseded by part number: 34306063
|
| 13. |
BN310446
|
[2] |
HOSE CLAMP
|
BN
#12, Stainless Steel
|
| 14. |
BN322536
|
[1] |
ADAPTER,1/2" Male NPT x 3/4" Hose Barb, Poly
|
BN
1/2" MPT x 3/4" Hose Barb, Poly Superseded by part number: 34304061
|
| 15. |
BN73560
|
[1] |
TEE
|
BN
3/4" NPT, Poly Superseded by part number: 321991A1
|
| 16. |
BN73565
|
[1] |
NIPPLE,3/4" Male NPT x 3/4" Male NPT, Poly
|
BN
3/4" Short Pipe, Poly Superseded by part number: 405788A1
|
| 17. |
BN50263
|
[4] |
BOLT,3/8"-16 X 1-3/4", Stainless Steel
|
BN
|
| 18. |
BN55359
|
[2] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 19. |
BN53862
|
[1] |
EPDM 3/4" ID X 8.5"
|
|
| 20. |
BN73655
|
[1] |
PLUG,1-1/4" Male NPT, Poly
|
BN
1 & 1/4 NPT Pipe Poly
|
