凯斯零件查询(FLX810) - FLEX-AIR APPLICATOR (10/03-8/09) (10-018) - PUMP STATION GROUP BRACKET, 60’ & 70’ Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
907 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
BN319418
|
[1] |
BRACKET, SUPPORTING
|
BN
Pump Station
|
| 2. |
BN304424
|
[2] |
BRACKET
|
BN
2" Valve, Lower
|
| 3. |
BN319416
|
[1] |
MOUNTING PLATE
|
BN
Ball Valve
|
| 4. |
BN304426
|
[1] |
BRACKET
|
BN
1" Valve, Lower
|
| 5. |
87267528
|
[1] |
PLATE
|
BN
1" Valve Mount
|
| 6. |
BN304465
|
[1] |
BRACKET
|
BN
Water Valve
|
| 7. |
87268844
|
[1] |
PLATE
|
BN
Mounting, Decal/Node
|
| 8. |
BN50138
|
[16] |
WASHER,1/4", SS
|
BN
|
| 9. |
BN50212
|
[10] |
BOLT,1/4"-20 x 3/4", Stainless Steel
|
BN
|
| 10. |
BN50671
|
[8] |
BOLT,1/4"-20 x 1.00", Stainless Steel
|
BN
|
| 11. |
BN52033
|
[2] |
BOLT,1/4"-20 X 5/8", Stainless Steel
|
BN
|
| 12. |
BN55359
|
[16] |
LOCK NUT,1/4"-20, SS
|
BN
|
| 13. |
BN319417
|
[1] |
MOUNT
|
BN
Ball Valve Mount
|
| 14. |
BN50232
|
[4] |
BOLT,5/16"-18 x 1.00", Stainless Steel
|
BN
|
| 15. |
BN55361
|
[4] |
NUT,5/16"-18, Nylon, Stainless
|
BN
|
| 16. |
BN50142
|
[8] |
WASHER,5/16", Stainless Steel
|
BN
|
| 17. |
343165A1
|
[1] |
PLATE
|
BN
1" Valve Mount
|
| 18. |
87268846
|
[1] |
COVER
|
BN
Electronic Node
|
| 19. |
BN50681
|
[4] |
BOLT,Hex, 1/4" - 20 x 1-1/2", SST
|
BN
1/4-20 X 1.5, HH, SS
|
