神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (08-001) - PUMP ASSY, FUEL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
423 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N3968F1 | [1] | PUMP ASSY, FUEL | |
| 1. | 24100R156F1 | [1] | PUMP ASSY, HYD | PUMP ASSY, HYD |
| 1-1. | 2437U164 | [1] | PUMP, FUEL | PUMP, FUEL |
| 1-2. | ZC15X02600 | [2] | CLAMP | KOB |
| 1-3. | 2444Z2252D1 | [1] | HOSE | KOB |
| 1-4. | 2444Z1233D7 | [1] | ELEC CONNECTOR | KOBCONNECTOR |
| 1-5. | 2446Z143 | [1] | STRAINER ASSY. | KOB |
| 2. | ZG24E12008 | [1] | NIPPLE | |
| 3. | ZG31U12000 | [1] | ELBOW | KOB |
| 4. | 2444Z2129D1 | [1] | NIPPLE | NIPPLE |
| 5. | 2444Z2201D2 | [1] | HOSE | KOB |
| 6. | ZC15X02600 | [2] | CLAMP | KOB |
| 7. | 2416T14910 | [1] | HANGER | |
| 8. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 9. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 10. | 2479Z843 | [1] | HARNESS | KOB |
| 11. | 2432Z309D2 | [5] | CLAMP | KOB |
