神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (08-007) - HYDR LINES/ P.N. 24100P2512F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
595 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P2512F1 | [1] | HYDR LINES | |
| 1. | 2444T2580 | [1] | TEE | KOB3/8" PF x 61mm Long (No O-Ring supplied) |
| 2. | 2420R537D400 | [1] | TUBE,9.60mm ID x 4000mm L | KOB4000mm Long (157-31/64 in) |
| 3. | ZH52F06000 | [2] | TEE | TEE |
| 4. | 2444R941D12 | [2] | FLEXIBLE HOSE | KOB |
| 5. | ZX52M06300 | [1] | HOSE | |
| 6. | ZH32X06008 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB90° -- 3/8"PFx1/2"PFx40mm Long (Same as ZD12P02400) |
| 6-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 7. | 2418T16645 | [1] | COVER | |
| 8. | 2432Z290D5 | [10] | CLIP | KOBWire Ties -- 365mm Long, NOT SHOWN Superseded by part number: PY01P01043D8 |
| 9. | ZH22F06000 | [2] | CONNECTION | KOB |
