神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (08-008) - HYDR LINES/ P.N. 24100N5640F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
330 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N5640F1 | [1] | HYDR LINES | |
| 1. | 2436R795F1 | [2] | VALVE, HOLDING, SEE FIGURE (C.P.M.) | |
| 3. | 2418P20146 | [1] | TUBE | |
| 4. | 2418P20147 | [1] | TUBE | |
| 5. | 2418P20148 | [1] | TUBE | |
| 6. | 2418P20149 | [1] | TUBE | |
| 7. | 2418P20150 | [1] | TUBE | |
| 8. | 2418P20151 | [1] | TUBE | |
| 9. | ZX53M06140 | [4] | HOSE | |
| 10. | 2416T21625 | [2] | BLOCK, TAPPED | |
| 11. | ZC36X35016 | [2] | CLAMP | KOB |
| 12. | ZC26X15009 | [4] | CLAMP | KOB |
| 13. | 2444T1342 | [2] | HYD CONNECTOR | KOB |
| 14. | ZA23F15008 | [2] | HYD CONNECTOR | KOB |
| 15. | ZS18C12035 | [4] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 16. | ZS18C14060 | [2] | SCREW,Hex, M14 x 60mm | KOBM14x2.0x60mm |
| 17. | ZS18C08040 | [4] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 19. | 2444Z3237D1 | [4] | CONNECTOR | |
| 20. | ZW16H12000 | [4] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 21. | ZW16H14000 | [2] | WASHER | KOBID 15 x OD 29 x Th 3.2mm |
| 22. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 24. | ZW26K12000 | [8] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 25. | ZD12P02900 | [2] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 26. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 27. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 28. | ZA23F15006 | [2] | HYD CONNECTOR | KOB3/8"PF - M22x1.50 x 37mm Long (No O-Ring supplied) |
