神钢零件查询(MD400LC) - EXCAVATOR BTW YS0101 - YS0200 (1/80-12/06) (08-013) - TRANSPORTING PARTS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
985 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100P1893F2 | [1] | TRANSPORTING PARTS | |
| 1. | 2416P10838 | [1] | BRACKET | |
| 2. | 2418T3887D1 | [1] | PLATE | KOB |
| 3. | 2432T1213D2 | [2] | CLAMP | KOB |
| 4. | ZS18C12025 | [2] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 5. | ZSI8C12065 | [2] | CAPSCREW | |
| 6. | ZW26X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 7. | 2444T1329D6 | [2] | PLUG | KOB Superseded by part number: ZF83H35000 |
| 8. | ZF93N35000 | [2] | NUT | KOB |
| 9. | 2444T1338D6 | [2] | PLUG | KOB Superseded by part number: ZF96N35000, ZF86P35000 |
| 10. | 2444Z2728D2 | [2] | PLUG | KOB3/8"PFx24.5mm Long (No O-Ring supplied) |
| 1 1. | 2444Z2729D2 | [2] | PLUG | KOB |
| 13. | 2432T3229 | [1] | LABEL | |
