神钢零件查询(MD450BLC) - EXCAVATOR BTW TS0201 - TS0394 (1/80-12/06) (11-008) - VALVE ASSY, PORT RELIEF Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
310 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R845F1 | [1] | VALVE | KOBCONSISTS OF THE FOLLOWING PARTS |
| . . | 2436R845F2 | [1] | VALVE | KOB |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 161. | ZD12P02290 | [1] | O-RING | KOB |
| 162. | ZD12P03000 | [1] | O-RING | KOBID 29.70 ± 0.29 x OD 36mm |
| 163. | 2436R845S163 | [1] | O-RING | KOB Superseded by part number: HD16P01000G1 |
| 164. | ZD85P01000 | [1] | RING, SNAP | KOBSNAP RING |
| 165. | ZD85P02290 | [1] | BACK-UP RING | KOB |
| 201. | 2436R845S201 | [1] | PLUG | KOB |
| 261. | ZD12P02800 | [1] | O-RING | KOBID 27.70 ± 0.27 x OD 34mm |
| 511. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER |
| 521. | 2436R819S521 | [1] | SPRING | KOB |
| 522. | 2436R683S522 | [1] | SPRING | KOB |
| 541. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT |
| 611. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET |
| 612. | 2436R682S521 | [1] | SEAT | KOB |
| 613. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT, SPRING |
| 621. | 2436R683S1 | [1] | SPRING | KOB |
| 641. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT |
| 651. | 2436R683S651 | [1] | SET SCREW | KOB |
| 663. | ZD12P00600 | [1] | O-RING | KOBID 05.80 ± 0.15 x OD 09mm |
| 671. | ZN11C12007 | [1] | NUT | KOBM12x1.75mm Superseded by part number: ZN18C12007 |
| 691. | NSS | [1] | NOT SOLD SEPARAT | CONFILTER |
