| . . | 2436U1390F1 | [1] | REGULATOR | KOBREGULATOR ASSY CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2436U1390F2 |
| . . | 2436U1390F2 | [1] | REGULATOR | KOBCONSISTS OF THE FOLLOWING PARTS |
| 412. | ZS23C08050 | [2] | CAP,Hex Socket Head, M8 x 50mm | KOBScrew -- M08x1.25x50mm |
| 413. | ZS23C08070 | [2] | SCREW,Hex Socket Head, M8 x 70mm | KOBM08x1.25x70mm |
| 436. | ZS23C06030 | [2] | SCREW,Hex Socket Head, M6 x 30mm | KOBM06x1.0x30mm |
| 438. | ZS23C06020 | [10] | SCREW,Hex Socket Head, M6 x 20mm | KOBM06x1.0x20mm Superseded by part number: ZS28C06020 |
| 496. | NSS | [5] | NOT SOLD SEPARAT | CONPLUG |
| 601. | NSS | [1] | NOT SOLD SEPARAT | CONCASING |
| 611. | NSS | [1] | NOT SOLD SEPARAT | CONLEVER, FEEDBACK |
| 612. | NSS | [1] | NOT SOLD SEPARAT | CONLEVER |
| 613. | NSS | [1] | NOT SOLD SEPARAT | CONLEVER |
| 614. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG |
| 615. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG, ADJUSTER |
| 621. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 622. | NSS | [1] | NOT SOLD SEPARAT | CONCASE, PISTON |
| 623. | NSS | [1] | NOT SOLD SEPARAT | CONROD |
| 624. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT, SPRING |
| 625. | 2436U1380S625 | [1] | SPRING | KOB |
| 626. | 2436U1380S626 | [1] | SPRING | KOB |
| 627. | NSS | [1] | NOT SOLD SEPARAT | CONRING, ADJUSTER |
| 628. | NSS | [1] | NOT SOLD SEPARAT | CONSETSCREW |
| 629. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER |
| 630. | 2436U1378S630 | [1] | NUT | KOB |
| 631. | NSS | [1] | NOT SOLD SEPARAT | CONSLEEVE |
| 641. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER, PILOT |
| 642. | NSS | [1] | NOT SOLD SEPARAT | CONSETSCREW |
| 643. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 644. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT, SPRING |
| 645. | NSS | [1] | NOT SOLD SEPARAT | CONRING, ADJUSTER |
| 646. | 2436U1378S646 | [1] | SPRING | KOBSPRING |
| 647. | NSS | [1] | NOT SOLD SEPARAT | CONSTOPPER |
| 648. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 651. | NSS | [1] | NOT SOLD SEPARAT | CONSLEEVE |
| 652. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 653. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT, SPRING |
| 654. | 2436U1378S654 | [1] | SPRING | KOB |
| 655. | 2436U1378S655 | [1] | SPRING | KOB |
| 656. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER |
| 708. | ZD12G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOBID 74.4mm x OD 77.5mm |
| 722. | ZD12P00600 | [3] | O-RING | KOBID 05.80 ± 0.15 x OD 09mm |
| 723. | ZD12P00700 | [1] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 724. | ZD12P00800 | [9] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 725. | ZD12P01000 | [1] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 728. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 730. | ZD12P02200 | [1] | O-RING | KOBID 21.80 ± 0.24 x OD 26mm |
| 732. | ZD12P01600 | [2] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 733. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 734. | ZD12G02500 | [1] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 735. | ZD12P01250 | [1] | O-RING | KOBID 12.3mm X OD 14.7mm |
| 755. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 756. | ZD12P02600 | [1] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 763. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 801. | ZN11C08005 | [3] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08005 |
| 814. | 2436U1318S814 | [1] | RING | RING |
| 836. | 2436U1318S836 | [1] | RING | KOB |
| 858. | ZR26X01500 | [2] | RING | KOBRetaining -- ID 15 x OD 16.2 x Th 1.0mm |
| 874. | NSS | [1] | NOT SOLD SEPARAT | CONPIN |
| 875. | NSS | [4] | NOT SOLD SEPARAT | CONPIN |
| 887. | NSS | [1] | NOT SOLD SEPARAT | CONPIN |
| 897. | NSS | [1] | NOT SOLD SEPARAT | CONPIN |
| 898. | NSS | [1] | NOT SOLD SEPARAT | CONPIN |
| 924. | 2441U722S924 | [1] | SET SCREW | KOB |
| 925. | 2436U1378S925 | [1] | SCREW | KOB |
| . . | 2436U1378R100 | [1] | REPAIR KIT | KOBCONSISTS OF ITEM 708, 722-725, 728, 730, 732-735, 755, 756 & 763 |
