神钢零件查询(MD450BLC) - EXCAVATOR BTW TS0201 - TS0394 (1/80-12/06) (11-023) - VALVE ASSY, BRAKE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
700 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1398F1 | [1] | VALVE | KOBCONSISTS OF THE FOLLOWING PARTS |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER ASSY |
| 3. | 2436U1398S3 | [2] | SEAT | KOBSEAT, SPRING |
| 4. | 2436U1398S4 | [2] | SEAT, SPRING | |
| 5. | 2436U1398S5 | [2] | SPRING | KOB |
| 7. | 2436U1398S7 | [2] | VALVE | KOB |
| 8. | 2436U1398S8 | [2] | SPRING | KOB |
| 9. | 2436U1398S9 | [2] | PLUG | KOB |
| 10. | ZD12P02900 | [2] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 12. | NSS | [2] | NOT SOLD SEPARAT | CONSCREW, DRIVE |
| 13. | 2436U1398S13 | [8] | SCREW | KOB |
| 14. | 2438U1017S29 | [1] | PLUG | KOB |
| 15. | NSS | [2] | NOT SOLD SEPARAT | CONCAP |
| 16. | NSS | [2] | NOT SOLD SEPARAT | CONBALL |
| 17. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| 18. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING |
| 19. | ZD12G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOB |
| 20. | ZD12P00800 | [4] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 21. | ZD85G04000 | [2] | BACK-UP RING | KOB |
| 22. | ZS23C12060 | [8] | SCREW,Hex Socket Head, M12 x 60mm | KOB |
| 23. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| 24. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER |
| 25. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| 26. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| . . | 2436U1398R100 | [1] | REPAIR KIT | KOBCONSISTS OF ITEM 15~23 |
| . . | 2436U1398R200 | [1] | SEAL KIT | KOBCONSISTS OF ITEM 10, 19-21, 26 |
