神钢零件查询(MD450BLC) - EXCAVATOR BTW TS0201 - TS0394 (1/80-12/06) (11-030) - MOTOR ASSY (SWING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
260 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U777F1 | [1] | MOTOR | KOB(SWING), CONSISTS OF THE FOLLOWING PARTS |
| 13. | 2441U777S13 | [1] | CYLINDER | KOBCYLINDER ASSY, CONSISTS OF ITEM 111, 121, 122, 131 |
| 18. | 2441U777S18 | [1] | PLATE | KOBPLATE ASSY, CONSISTS OF ITEM 113, 123 |
| 20. | 2441U777S20 | [1] | BODY | KOBCOVER ASSY, VALVE, CONSISTS OF ITEM 303, 451 |
| 23. | 2441U777S23 | [1] | REPAIR KIT | KOBCOVER ASSY, BRAKE, CONSISTS OF ITEM 452, 701 |
| 101. | 2441U777S101 | [1] | SHAFT | KOB |
| 106. | 2441U777S106 | [1] | SPACER | KOB |
| 111. | NSS | [1] | NOT SOLD SEPARAT | CONCYLINDER |
| 113. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING |
| 114. | 2441U777S114 | [4] | SPRING | KOBCONED DISK |
| 115. | 2441U777S115 | [1] | SHIM | KOB |
| 121. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON |
| 122. | NSS | [9] | NOT SOLD SEPARAT | CONSHOE |
| 123. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 124. | 2441U777S124 | [1] | PLATE | KOBSHOE |
| 131. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, VALVE |
| 133. | NSS | [1] | NOT SOLD SEPARAT | CONRING, GUIDE |
| 301. | 2441U777S301 | [1] | BEARING ASSY | KOBCASING |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER, VALVE |
| 304. | 2441U777S304 | [1] | GUARD | KOBFRONT |
| 401. | ZS23C12160 | [12] | SCREW,Hex Socket Head, M12 x 160mm | KOBM12x1.75x160mm |
| 402. | ZS23C12045 | [2] | SCREW,Hex Socket Head, M12 x 45mm | KOBM12x1.75x45mm Superseded by part number: ZS28C12045 |
| 403. | ZS23C08025 | [6] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 404. | ZS23C16035 | [12] | SCREW,Hex Socket Head, M16 x 35mm | KOBM16x2.0x35mm |
| 431. | ZS16X07500 | [1] | RING | |
| 432. | ZR16X05000 | [1] | RING | KOBRetaining -- ID 50 x OD 64 x Th 2.0mm |
| 436. | ZR26X07200 | [1] | SNAP RING | KOB |
| 443. | 24100U473S443 | [1] | ROLLER BEARING | KOB |
| 444. | 2441U777S444 | [1] | NEEDLE BEARING | KOB |
| 445. | 2441U777S445 | [1] | RACE | KOB Superseded by part number: LS15V00005S445 |
| 451. | NSS | [1] | NOT SOLD SEPARAT | CONPIN |
| 452. | NSS | [1] | NOT SOLD SEPARAT | CONPIN |
| 462. | 2441U436S468 | [2] | PLUG | KOB |
| 463. | ZE82T06000 | [2] | PLUG | KOBPipe, 3/8" PT |
| 464. | 2441U436S469 | [2] | PLUG | KOB |
| 471. | ZD12G13000 | [1] | O-RING,129.40mm ID x 135.60mm OD x 3.10mm | KOBID 129.40 ± 1.05 x OD 135mm |
| 472. | 24100U473S472 | [1] | O-RING | KOB |
| 473. | 2453U168S702 | [1] | O-RING | KOB |
| 484. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 485. | ZD12P02400 | [2] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 491. | 2441U777S491 | [1] | OIL SEAL | KOB Superseded by part number: 24100U473S491 |
| 492. | 2441U777S492 | [1] | OIL SEAL | KOB |
| 701. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER, BRAKE |
| 702. | 2441U777S702 | [1] | PISTON | KOBBRAKE |
| 703. | 2441U777S703 | [1] | COUPLING | KOB |
| 704. | 2441U777S704 | [1] | SPACER | KOB |
| 706. | 2441U564S735 | [1] | O-RING,3.5mm Thk x 173mm ID, 75 Duro | KOB Superseded by part number: YN15V00025S489 |
| 707. | 2441U777S707 | [1] | O-RING | KOB |
| 710. | 2441U777S710 | [1] | SHIM | KOB |
| 712. | 2441U777S712 | [4] | SPRING | KOBCONED DISK |
| 741. | 2441U777S741 | [8] | STEP PLATE | KOBSEPARATE |
| 742. | 2441U736S742 | [7] | CLUTCH PLATE | KOBFRICTION |
| 761. | 2441U667S466 | [2] | PLUG | KOB1/4" PF |
| 762. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
