| . . | 24100J11055F1 | [1] | POWER-PLANT YS0201, LS0201 to YS0279, LS0268 | |
| . . | 24100J11055F3 | [1] | POWER-PLANT YS0280, Start Serial: LS0268 | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONPUMP ASSY, CONNECT, SEE FIGURE 05-004 YS0201, LS0201 to YS0279, LS0258 |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONENGINE MOUNT |
| 3. | 2420T6997D1 | [2] | SHIM (1.6) | |
| 4. | 2420T6997D2 | [2] | SHIM (2.3) | |
| 5. | 2420T6997D3 | [2] | SHIM (4.5) | |
| 6. | 2444R1042 | [1] | FLEXIBLE HOSE | KOB |
| 8. | 2418P20189D1 | [1] | PLATE | |
| 9. | 2418P20189D2 | [1] | PLATE | |
| 11. | 2416T22469 | [1] | STAY | STAY |
| 12. | ZC15X08000 | [4] | CLIP | KOB |
| 14. | 2427U407F1 | [1] | CONTAINER | KOB |
| 14-1. | 2427U407S1 | [1] | CONTAINER | KOB |
| 14-2. | 2427U407S2 | [1] | CAP | KOB |
| 14-3. | 2427U407S3 | [1] | CAP | KOB |
| 14-4. | 2427U203S5 | [1] | SWITCH | KOB |
| 14-5. | 2427U203S3 | [1] | LABEL | KOB |
| 15. | 2416P14230 | [1] | BRACKET | KOB |
| 16. | 2416T17287 | [1] | SUPPORT | |
| 17. | NSS | [1] | NOT SOLD SEPARAT | CONAIR CLEANER ASSY, SEE FIGURE 05-005 |
| 18. | 2432R222F1 | [2] | BAND ASSY | BAND ASSY |
| 18-1. | 2432R222 | [1] | BAND | |
| 18-3. | 2432R222S3 | [1] | CAPSCREW | |
| 18-4. | 2432R222S4 | [2] | NUT | |
| 18-5. | 2432R222S5 | [2] | WASHER YS0227, Start Serial: LS0219 | |
| 20. | 2444R1043 | [1] | FLEXIBLE HOSE | KOB |
| 23. | 2450R163F1 | [1] | INDICATOR | KOB Superseded by part number: LE11P01015F1 |
| 24. | 2444Z1600D7 | [1] | ELBOW UNION | KOBUnion Elbow |
| 25. | ZC15X13000 | [4] | CLIP | KOB |
| 26. | ZC15X10500 | [2] | CLIP | KOB |
| 27. | 2420T6696 | [1] | PIPE | PIPE |
| 28. | 2444Z1411D3 | [1] | KNUCKLE JOINT | KOBSTRAIGHT HUMP |
| 34. | 2444Z1293D10 | [1] | LUBE NIPPLE | KOBNipple, Hose -- 3/8" PTx46mm Long |
| 36. | NSS | [1] | NOT SOLD SEPARAT | CONRADIATOR ASSY, SEE FIGURE 05-006 |
| 37. | 2444R2492D160 | [1] | FLEXIBLE HOSE | KOBYS0424, Start Serial: LS0433 |
| 38. | 2444R2492D360 | [2] | HOSE | KOBYS0424, Start Serial: LS0433 |
| 39. | 2432R226D10 | [4] | CLIP | KOBClamp, Double -- ID 20 x 77mm Long YS0424, Start Serial: LS0433 Superseded by part number: ZC48X20014 |
| 40. | ZC15X01500 | [6] | CLIP | KOBYS0424, Start Serial: LS0433 |
| 41. | 2432R225D8 | [1] | CLIP | KOBClamp, Single -- ID 19.1 x 51.55mm Long YS0424, Start Serial: LS0433 Superseded by part number: ZC46X19011 |
| 43. | 2416T21618 | [1] | STAY | |
| 46. | 4018Z1D5 | [1] | HOSE YS0201, LS0201 to YS0423, LS0432 | HOSE YS0201, LS0201 to YS0423, LS0432 |
| 47. | 4018Z1D16 | [2] | TUBE | KOBYS0201, LS0201 to YS0423, LS0432 |
| 48. | 2420Z795D7 | [1] | HOSE | KOB |
| 50. | 2420Z912D3 | [1] | FLEXIBLE HOSE | KOB |
| 51. | ZC15X01000 | [9] | CLIP | KOBYS0201, LS0201 to YS0423, LS0432 |
| . . | ZC15X01000 | [3] | CLIP | KOBYS0424, Start Serial: LS0433 |
| 55. | 2420T6786 | [4] | BOLT,M12 x 1.75 x 25mm | KOBM12x1.75x25mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C12025 |
| 56. | ZS18C10025 | [14] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 61. | ZS18C08030 | [4] | SCREW,Hex, M8 x 30mm | KOBM08x1.25x30mm |
| 63. | ZS13C16040 | [4] | SCREW | KOBM16x2.0x40mm |
| 65. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 66. | ZN18C10008 | [5] | NUT | KOBM10x1.50mm |
| 73. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 74. | ZW26X10000 | [19] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 75. | ZW22X20000 | [8] | LOCK WASHER | KOBID 20 x OD 33.8 x Th 5.1mm |
| 77. | ZW22X16000 | [4] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 79. | 2432Z290 | [6] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 80. | ZW11X16000 | [4] | WASHER | KOBID 16 x OD 30 x Th 2.3mm |
| 81. | 2446U234 | [1] | FILTER | KOBSEE FIGURE 05-007 YS0201, LS0201 to YS0359, LS0365 Superseded by part number: 2446U234F3 |
| 83. | 4018Z1D1 | [1] | TUBE | KOB |
| 84. | 2418P21193 | [1] | EXHAUST SYSTEM PIPE | KOB |
| 85. | 2420T6903 | [1] | RIGID TUBE | KOB |
| 86. | ZW26X12000 | [1] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 87. | ZN18C12010 | [1] | NUT | KOBM12x1.75mm |
| 91. | 2479Z1518D1 | [1] | INSULATOR | KOB |
| 92. | 2479Z1501D2 | [1] | INSULATOR | KOB |
| 93. | 2479Z1502D1 | [1] | INSULATOR | KOB |
| 94. | 2432R225D5 | [2] | CLIP | KOB Superseded by part number: ZC46X12011 |
| 95. | 2432Z290D3 | [3] | CLIP | KOBWire Ties -- 154mm Long Superseded by part number: PY01P01043D3 |
| 96. | NSS | [2] | NOT SOLD SEPARAT | CONCLIP, RADIATOR UNIT |
| 97. | ZS13C20050 | [8] | SCREW | KOBM20x2.50x50mm |
| 98. | ZW13H20000 | [8] | WASHER | KOBID 20 x OD 40 x Th 4.5mm |
| 99. | 2432R226D7 | [4] | CLIP Clamp, Double -- ID 16 x 66mm Long YS0201, LS0201 to YS0423, LS0432 | CLIP Clamp, Double -- ID 16 x 66mm Long YS0201, LS0201 to YS0423, LS0432 |
| 100. | 2416P13419 | [1] | BRACKET | |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONHOSE, SEE FIGURE 05-006 - ITEM 8 |
| 102. | 2432T2492 | [1] | CLAMP | KOB Superseded by part number: LQ12P01003P1 |
| 103. | ZS18C12040 | [1] | SCREW,Hex, M12 x 40mm | KOBM12x1.75x40mm |
| 104. | 2420P1536 | [1] | PIPE | |
| 106. | 2444Z3330 | [1] | FLEXIBLE HOSE | KOB |
| 107. | 2432R225D7 | [1] | CLIP | KOBYS0201, LS0201 to YS0423, LS0432 Superseded by part number: ZC46X16011 |
| 108. | 2446U234F2 | [1] | SEPARATOR | KOBFILTER ASSY, SEE FIGURE 05-007 YS0360, Start Serial: LS0366 Superseded by part number: 2446U234F3 |
| . . | MITSUBISHI PARTS NO. | [1] | | |
| 52. | VAME058950 | [1] | HOSE | KOBBREATHER |
| 53. | VAMS666012 | [1] | HOSE CLAMP | KOB |
