| . . | 24100J11131P1 | [1] | AIR-LINES, UPP | |
| . . | 24100J11131P2 | [1] | AIR-LINES, UPP | |
| 1. | R38N0012 | [1] | RESERVOIR | KOB |
| 2. | 2446R316F1 | [1] | VALVE PRESSURE RELIE | KOBYS0201, LS0201 to YS0279, LS0267 |
| . . | 2446R335F1 | [1] | VALVE PRESSURE RELIE | KOBYS0280, Start Serial: LS0268 |
| 3. | 2479R1338 | [1] | SENDER UNIT | KOB |
| 4. | 2436R339 | [2] | COCK, DRAIN | KOB |
| 5. | 2436Z274D4 | [1] | VALVE PRESSURE RELIE | KOB |
| 6. | 2420Z1224 | [1] | FLEXIBLE HOSE | KOBGuard -- ID 22 x OD 26 x 300mm Long (11-13/16 in) |
| 7. | ZC15X02600 | [1] | CLAMP | KOB |
| 8. | R38T0001D4 | [1] | VALVE PRESSURE RELIE | KOB |
| 9. | ZG51U04000 | [1] | TEE | KOB |
| 10. | ZG21E04000 | [3] | HYD CONNECTOR | KOBNIPPLE |
| 11. | 2416T22478 | [1] | U-BRACKET | KOBBRACKET |
| 12. | B20T0041 | [2] | U-BOLT | KOB |
| 13. | ZN18C08007 | [10] | NUT | KOBM08x1.25mm |
| 14. | ZG21B08004 | [2] | BUSHING | KOBBUSHING |
| 16. | 2436Z316 | [2] | VALVE | KOB |
| 17. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 18. | ZS18C06014 | [2] | SCREW,Hex, M6 x 14mm | KOBM06x1.0x14mm |
| 19. | ZW16X05000 | [2] | WASHER | KOB |
| 20. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 21. | 2420R349D030 | [1] | HOSE,300.00 mm | KOB |
| 22. | 2420R349D150 | [1] | HOSE,6.35mm ID x 1500mm L | KOBPF 1/4 |
| 23. | 2420R349D330 | [1] | HYDRAULIC HOSE,6.35 mm ID x 3300.00 mm | KOBYS0201, LS0201 to YS0228, LS0222 Superseded by part number: HX21E04330DX |
| . . | 2420R349D340 | [1] | HOSE | KOB3400mm Long (133-55/64 in) YS0229, Start Serial: LS0223 Superseded by part number: HX21E04340DX |
| 24. | 2444Z2079 | [1] | HYD CONNECTOR | KOB |
| 25. | ZS18C10025 | [6] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 26. | ZW26X10000 | [13] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 27. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 28. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 29. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 30. | ZH22Z04000 | [3] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 31. | 2444Z1293D6 | [1] | LUBE NIPPLE | KOBNipple, Hose -- 1/4"PTx39mm Long |
| 32. | 2444Z1624D6 | [1] | FLEXIBLE HOSE | KOBAIR |
| 33. | ZC15X01500 | [2] | CLIP | KOB |
| 34. | R38N0014 | [1] | KIT DIA, CRAWLER EXC | KOBVALVE, HORN |
| 35. | ZX15K04020 | [1] | RIGID TUBE | KOB |
| 36. | 2447U2 | [1] | HORN | KOB Superseded by part number: 2447U46 |
| 37. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 38. | 2421U10F3 | [1] | PUMP | KOB Superseded by part number: 2421U10F4 |
| 39. | NSS | [1] | NOT SOLD SEPARAT | CONREEL ASSY, HOSE |
| 40. | ZG51U08000 | [1] | TEE | KOB |
| 41. | ZG31B04000 | [1] | ELBOW | ELBOW |
| 42. | ZS18C12030 | [4] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 43. | ZW26X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 44. | 2432R225D5 | [9] | CLIP | KOB Superseded by part number: ZC46X12011 |
| 45. | ZS18C08035 | [2] | SCREW,Hex, M8 x 35mm | KOBM08x1.25x35mm |
| 47. | 2444T1169 | [1] | HYD CONNECTOR | KOB |
| 51. | 2418P21127 | [1] | RIGID TUBE | KOB |
| 53. | 2444Z1737D3 | [1] | HYD CONNECTOR | KOB |
| 54. | ZH21K04004 | [1] | HYD CONNECTOR | KOB |
| 55. | 2444T1170 | [1] | HYD CONNECTOR | KOB |
| 56. | 2432Z290D2 | [1] | CLIP | KOBWire Ties -- 100mm Long Superseded by part number: YT50C01100P1 |
| 57. | ZG21U04000 | [1] | SOCKET | KOB |
| 58. | ZG21E08004 | [1] | LUBE NIPPLE | KOBNIPPLE |
| 59. | 2420R349D075 | [1] | HOSE | KOB750mm Long (29-1/2 in) Superseded by part number: 2444R3019D3 |
| 60. | ZH32Z04000 | [2] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 61. | ZS18C08014 | [2] | SCREW,Hex, M8 x 14mm | KOBM08x1.25x14mm |
| 62. | ZN18C10008 | [7] | NUT | KOBM10x1.50mm |
| 63. | ZH31K04004 | [1] | ELBOW | KOB |
| 64. | 2408T328 | [1] | BLOCK, (F 2) | |
| 65. | ZG21E02000 | [1] | HYD CONNECTOR | KOBNIPPLE, (F 2) |
| 66. | ZH21K04002 | [1] | HYD CONNECTOR | KOB(F 2) |
| 67. | 2444Z3387 | [2] | HYD CONNECTOR | KOB |
| 68. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| . . | MITSUBISHI PARTS NO. | [1] | | |
| 46. | MC802148 | [1] | GOVERNOR | |
| 48. | MH035107 | [4] | GASKET | |
| 49. | MH032014 | [1] | HOSE | |
| 50. | MH032853 | [1] | HOSE | |
