现代零件查询R800LC-7A ARM HYD PIPING(8.0M, L/REACH, #0039-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
212 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
31ND-60710
|
[1] |
PIPE WA
|
|
| 3. |
31ND-60720
|
[1] |
PIPE WA
|
|
| 4. |
31ND-60730
|
[2] |
HOSE ASSY-FLG 0X90
|
|
| 4. |
31ND-60731
|
[2] |
HOSE ASSY-FLG(0X90)
|
|
| 5. |
31ND-60740
|
[2] |
HOSE ASSY-FLG 0X90
|
|
| 5. |
31ND-60741
|
[2] |
HOSE ASSY-FLG(0X90)
|
|
| 6. |
31ND-51001
|
[4] |
CLAMP ASSY
|
|
| 7. |
31ND-51031
|
[4] |
CLAMP ASSY
|
|
| 8. |
P174-200106
|
[16] |
FLANGE-HYD,SPLIT
|
|
| 9. |
Y171-027004
|
[8] |
O-RING
|
|
| 10. |
S017-16045D
|
[8] |
BOLT-HEX
|
|
| 11. |
S411-160006
|
[8] |
WASHER-SPRING
|
|
| 12. |
S109-120506
|
[32] |
BOLT-SOCKET
|
|
