现代零件查询R800LC-7A ARM SAFETY LOCK SYSTEMEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
155 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
31ND-53030
|
[1] |
ARM SAFETY LOCK CYL
|
|
| 1. |
31ND-53031
|
[1] |
ARM SAFETY LOCK CYL
|
|
| 1-0. |
@
|
[1] |
ARM CYL SUB ASSY
|
|
| 1-1. |
31ND-55031
|
[1] |
SAFETY LOCK VALVE
|
|
| 1-1-1. |
DRV-100A
|
[1] |
RELIEF VALVE
|
|
| 1-1-2. |
AS568-6
|
[1] |
SEAL KIT
|
|
| 1-2. |
XKCD-00577
|
[1] |
PIPE ASSY
|
|
| 1-3. |
XKCD-00683
|
[1] |
O-RING
|
|
| 1-4. |
XKCD-00578
|
[4] |
BOLT-HEX SOCKET
|
|
| 1-5. |
XKCD-00462
|
[8] |
WASHER-SPRING
|
|
| 1-6. |
XKCD-00683
|
[1] |
O-RING
|
|
| 1-7. |
XKCD-00469
|
[4] |
BOLT-HEX SOCKET
|
|
| 2. |
P930-042172
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 2. |
P930-042200
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 3. |
P930-062184
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 3. |
P930-062212
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 4. |
X511-104514
|
[1] |
CONNECTOR-LONG,ORFS
|
|
| 5. |
X511-104524
|
[1] |
CONNECTOR-LONG,ORFS
|
|
| 6. |
X820-045151
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 7. |
P220-110102
|
[1] |
PLUG-HEX
|
|
