神钢零件查询(MD450BLC) - EXCAVATOR BTW TS0201 - TS0394 (1/80-12/06) (06-005) - SPRING ASSY, TRACK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
494 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N5888F1 | [1] | SPRING | KOB Superseded by part number: LS54DU0001F1 |
| 1. | 2438N258 | [1] | CYLINDER | KOB Superseded by part number: 2438N227 |
| 2. | 2416N3503 | [1] | U-BRACKET | KOB |
| 3. | 2420T6673 | [1] | NUT | KOB |
| 4. | ZP26D13110 | [1] | ROLL PIN | KOB |
| 5. | 2417P266 | [1] | SPRING | KOB Superseded by part number: LS54DU1006P1 |
| 6. | ZS23C20080 | [4] | SCREW,Hex Socket Head, M20 x 80mm | KOBM20x2.5x80mm |
| 7. | 2444R923 | [1] | LUBE NIPPLE | KOBLube -- 5/8" - 18 UNF, Straight YS0201, Start Serial: LS0201 Superseded by part number: 2444P803 |
| . . | 2444P803 | [1] | LUBE NIPPLE,5/8" - 18 x 64mm L, 19mm Hex | KOB5/8" - 18 UNF, Straight YS0302, Start Serial: LS0310 |
| 8. | 2439P176 | [1] | PISTON | KOB |
| 9. | R45T0003D7 | [1] | SEAL | KOBID 100 x OD 120 x Th 15mm |
| 10. | 2445Z1080D4 | [1] | DUST CAP | KOB Superseded by part number: JH01V00007S9 |
| 11. | 2419T4748 | [2] | PIN | KOB Superseded by part number: LQ54D01023P1 |
