神钢零件查询(MD450BLC) - EXCAVATOR BTW TS0201 - TS0394 (1/80-12/06) (06-006) - REDUCTION UNIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
471 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J10364F1 | [1] | HYDRAULIC MOTOR | KOB |
| 1. | 2410N510F1 | [1] | SPINDLE | KOB |
| 1-1. | 2410J273 | [1] | SPINDLE | SPINDLE |
| 1-2. | 2418N4686 | [1] | RETAINER | RETAINER |
| 2. | 2418J263 | [1] | HUB | HUB |
| 3. | ZD57F36637 | [1] | FLOAT | KOB Superseded by part number: ZD58F36637 |
| 4. | 2418N4687 | [1] | RETAINER | HIT |
| 5. | 2425R216 | [2] | BEARING | KOB |
| 6. | 24100P2517F1 | [1] | COVER | KOB |
| 6-1. | 2414J1866 | [1] | COVER | KOB |
| 6-2. | 2401P1164 | [1] | RING GEAR | KOB |
| 6-3. | A19P0009D103 | [10] | PIN | PIN |
| 7. | 2425Z532 | [4] | BEARING | KOB |
| 8. | 2401J145 | [1] | RING GEAR | KOB |
| 9. | 2418T18904 | [1] | SPACER | KOB |
| 10. | 2418T18903 | [1] | SPACER | KOB |
| 11. | 2418T18902 | [1] | SPACER | KOB |
| 12. | 2401P1161 | [1] | SUN GEAR | KOB |
| 13. | 2401P1162 | [1] | SUN GEAR | KOB |
| 14. | 2401P1163 | [1] | SUN GEAR | KOB |
| 15. | 2413J369 | [1] | DIFF. SPIDER | KOB |
| 16. | 2413J368 | [1] | DIFF. SPIDER | KOB |
| 17. | 2413N437F1 | [1] | DIFF. SPIDER | KOB |
| 17-1. | 2413N437 | [1] | DIFF. SPIDER | KOB |
| 17-2. | 2410T335 | [4] | ROLLER SHAFT | KOB |
| 18. | ZE82T12000 | [2] | PLUG | KOB3/4" PT |
| 19. | 2418T18905 | [1] | SPACER | KOB |
| 21. | ZR16X05500 | [4] | RING | KOB |
| 22. | 2401P1160 | [4] | PINION | KOB |
| 23. | 2401P1158 | [4] | PINION | KOB |
| 24. | 2401P1159 | [4] | PINION | KOB |
| 25. | ZP26D08032 | [4] | PIN | KOBRoll -- OD 08 x 32mm Long |
| 26. | ZP26D10040 | [4] | ROLL PIN | KOBOD 10 x 40mm Long |
| 27. | 2418T9478 | [10] | LOCKING PLATE | KOB |
| 28. | ZS23C06014 | [10] | CAPSCREW M06x1.0x14mm | CAPSCREW M06x1.0x14mm |
| 29. | 2410T337 | [4] | ROLLER SHAFT | KOB |
| 30. | 2410T336 | [4] | ROLLER SHAFT | KOB |
| 31. | 2418T18900D1 | [4] | THRUST WASHER | KOB |
| 32. | 2418T18901 | [8] | THRUST WASHER | KOB |
| 33. | 2418T18900D2 | [4] | THRUST WASHER | KOB |
| 34. | ZS23C10035 | [20] | SCREW,Hex Socket Head, M10 x 35mm | KOBM10x1.50x35mm |
| 35. | ZS23C20085 | [20] | SCREW,Hex Socket Head, M20 x 85mm | KOBM20x2.5x85mm |
| 36. | 2419T5866 | [8] | PIN | KOB |
| 37. | ZS23C12040 | [20] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| 38. | ZS83C12035 | [2] | SCREW | KOB |
| 39. | ZS23C20060 | [16] | SCREW,Hex Socket Head, M20 x 60mm | KOBM20x2.5x60mm |
| 40. | 2425Z524 | [4] | ROLLER BEARING | KOB |
| 41. | 2425Z525 | [4] | ROLLER BEARING | KOB |
| 42. | 2420T6703D1 | [1] | SHIM | KOB(0.5) |
| 43. | 2420T6703D2 | [1] | SHIM | KOB(1.0) |
| 44. | 2420T6703D3 | [1] | SHIM | KOB(1.5) |
| 45. | 2420T6703D4 | [1] | SHIM | KOB(2.0) |
| 46. | 2418T19078 | [2] | SHIM | KOB |
| 53. | 2420T6705D1 | [1] | SHIM | KOB(1.0) |
| 54. | 2420T6705D2 | [1] | SHIM | KOB(1.1) |
| 55. | 2420T6705D3 | [1] | SHIM | KOB(1.2) |
| 56. | 2420T6705D4 | [1] | SHIM | KOB(1.3) |
| 57. | 2420T6705D5 | [1] | SHIM | KOB(1.4) |
| 58. | 2420T6705D6 | [1] | SHIM | KOB(1.5) |
| 59. | 2420T6705D7 | [1] | SHIM | KOB(1.6) |
| 60. | 2420T6705D8 | [1] | SHIM | KOB(1.7) |
| 61. | 2420T6705D9 | [1] | SHIM | KOB(1.8) |
| 62. | 2420T6705D10 | [1] | SHIM | KOB(1.9) |
| 63. | 2420T6705D11 | [1] | SHIM | KOB(2.0) |
| 64. | 2420T6705D12 | [1] | SHIM (2.1) | SHIM (2.1) |
| 65. | 2420T6705D13 | [1] | SHIM | KOB(2.2) |
| 66. | 2420T6705D14 | [1] | SHIM | KOB(2.3) |
| 67. | 2420T6705D15 | [1] | SHIM | KOB(2.4) |
| 68. | 2420T6705D16 | [1] | SHIM | KOB(2.5) |
| 69. | 2420T6705D17 | [1] | SHIM | KOB(2.6) |
| 70. | 2420T6705D18 | [1] | SHIM | KOB(2.7) |
| 71. | 2420T6705D19 | [1] | SHIM (2.8) | SHIM (2.8) |
| 72. | 2420T6705D20 | [1] | SHIM | KOB(2.9) |
| 73. | 2420T6705D21 | [1] | SHIM | KOB(3.0) |
| 74. | 2420T6705D22 | [1] | SHIM | KOB(0.1) YS0264, Start Serial: LS0245 |
| 75. | 2420T6705D23 | [1] | SHIM | KOB(0.2) YS0264, Start Serial: LS0245 |
| 76. | 2420T6705D24 | [1] | SHIM | KOB(0.3) YS0264, Start Serial: LS0245 |
