神钢零件查询(MD450BLC) - EXCAVATOR BTW TS0201 - TS0394 (1/80-12/06) (06-008) - RING, SLEWING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
685 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2425U239F1 | [1] | RING, SLEWING BEARING ASSY YS0201, LS0201 to YS0224, LS0219 | RING, SLEWING BEARING ASSY YS0201, LS0201 to YS0224, LS0219 |
| . . | 2425U239F2 | [1] | BEARING ASSY YS0225, LS0220 to YS0275, LS0263 | |
| . . | 2425U239F3 | [1] | SLEWING RING | KOBYS0276, Start Serial: LS0264 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONRACE, OUTER |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONRACE, INNER |
| 3. | 2425T277 | [77] | BALL | KOB |
| 4. | 2425U239S4 | [77] | RETAINER | |
| 5. | 2425U239S5 | [1] | SEAL | SEAL |
| 6. | 2425U239S6 | [1] | SEAL | KOB |
| 7. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG |
| 9. | 2419T1964D8 | [1] | PIN, TAPER OD 10 x 110mm Long | PIN, TAPER OD 10 x 110mm Long |
