神钢零件查询(MD450BLC) - EXCAVATOR BTW TS0201 - TS0394 (1/80-12/06) (06-007) - RING, SLEWING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
582 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N5635F1 | [1] | RING, SLEWING BEARING ASSY YS0201, LS0201 to YS0224, LS0217 | RING, SLEWING BEARING ASSY YS0201, LS0201 to YS0224, LS0217 |
| . . | 24100N5635F2 | [1] | BEARING ASSY YS0201, LS0220 to YS0275, LS0263 | |
| . . | 24100N5635F3 | [1] | RING, SLEWING YS0274, Start Serial: LS0264 | RING, SLEWING YS0274, Start Serial: LS0264 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBEARING, SEE FIGURE 06-007 YS0201, LS0201 to YS0224, LS0217 |
| 2. | 2418P20106 | [2] | RIGID TUBE | KOB |
| 3. | 2410T306 | [2] | KNUCKLE JOINT | KOB |
| 4. | ZF33E08004 | [2] | ELBOW | KOB |
| 5. | ZF23E08004 | [2] | HYD CONNECTOR | KOB |
| 6. | ZG91S02000 | [3] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 7. | ZC45X08007 | [2] | CLAMP | KOB Superseded by part number: ZC46X08007 |
| 8. | ZS13C06010 | [2] | SCREW | KOBM06x1.0x10mm Superseded by part number: ZS18C06010 |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONBEARING, SEE FIGURE 06-007 YS0225, LS0220 to YS0275, LS0263 |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONRING, SLEWING, SEE FIGURE 06-007 YS0276, Start Serial: LS0264 |
