神钢零件查询(MD450BLC) - EXCAVATOR BTW TS0201 - TS0394 (1/80-12/06) (06-010) - INSTAL, CRAWLER TRACK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
377 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J10511F1 | [1] | INSTAL, CRAWLER TRACK | |
| 1. | 24100J10883F2 | [2] | LINK | KOB |
| 1-1. | 2424N189D1 | [51] | LINK | KOB(RH) |
| 1-2. | 2424N189D2 | [51] | LINK | KOB(LH) |
| 1-3. | 2424P162D1 | [2] | CONNECTING LINK | KOB(RH) |
| 1-4. | 2424P162D2 | [2] | CONNECTING LINK | KOB(LH) |
| 1-5. | 2405P510 | [51] | BUSHING | KOB Superseded by part number: 77250361, 2405P710 |
| 1-6. | 2419P1783 | [51] | PIN | KOBTRACK |
| 1-7. | 2405P511 | [2] | BUSHING | KOB |
| 1-8. | 2419P952 | [2] | PIN | KOB Superseded by part number: 2419T5972, 2419P3804 |
| 1-9. | 2418T4681 | [4] | COLLAR CLAMP | KOB |
| 1-10. | 2419T2051 | [2] | PIN | KOB |
| 1-11. | 2445Z1440 | [102] | SEAL | KOB |
| 2. | 2420T5491D1 | [424] | SCREW | KOBSHOE |
| 3. | 2420Z1284 | [424] | NUT | KOBSHOE |
| 4. | 2424N191 | [106] | SHOE | KOB(600) Superseded by part number: 2424N252 |
| . . | 24100J10511F2 | [1] | INSTAL, CRAWLER TRACK CONSISTS OF ITEM 1, 2, 3 & 5 | |
| 5. | 2424N190D2 | [106] | SHOE | KOBSHOE (800) Superseded by part number: 2424N247 |
| . . | 24100J10511F3 | [1] | INSTAL, CRAWLER TRACK CONSISTS OF ITEM 1, 2, 3 & 6 | |
| 6. | 2424N190 | [106] | SHOE | KOBSHOE (900) Superseded by part number: 2424N248 |
